Viewsonic PA503SP data projector Standard throw projector 3600 ANSI lumens DLP SVGA (800x600) 3D Grey, White

Viewsonic PA503SP data projector Standard throw projector 3600 ANSI lumens DLP SVGA (800x600) 3D Grey, White

Model PA503SPEAN 766907975611

80 specifications
  • Noise31 dB
  • TypeStandard throw projector
  • Weight2.2 kg
  • ColourGrey, White
  • Projector brightness3600 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Noise
31 dB
Type
Standard throw projector
Weight
2.2 kg
Colour
Grey, White
Projector brightness
3600 ANSI lumens
Light source type
Lamp
Brand
Viewsonic
Model
PA503SP
Part number
PA503SP
EAN / UPC
766907975611
Also known as
Viewsonic PA503SP data projector Standard throw projector 3600 ANSI lumens DLP SVGA (800x600) 3D Grey, White

Specifications

80 specifications in 16 groups

Projector

Projector brightness3600 ANSI lumens
Projection technologyDLP
Projector native resolutionSVGA (800x600)
Supported aspect ratios4:3, 16:9
Screen size compatibility762 - 7620 mm (30 - 300")
Projection distance1.19 - 13.11 m
Contrast ratio (dynamic)22000:1
Number of colours1.073 billion colours
Horizontal scan range15 - 102 kHz
Vertical scan range23 - 120 Hz
Keystone correction, vertical-40 - 40°
Matrix size1.4 cm (0.55")
Matrix typeDMD

Light source

Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)15000 h
Lamp power190 W

Lens system

Focal length range22 - 24.1 mm
Aperture range (F-F)2.56 - 2.68
Zoom capabilityYes
Digital zoom2x
Optical zoom1.1x
Throw ratio1.96 - 2.15:1
Offset120%

Video

Analog signal format systemNTSC, PAL, SECAM
3DYes
Supported graphics resolutions640 x 480 (VGA), 1920 x 1080 (HD 1080)
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Ports & interfaces

VGA (D-Sub) ports quantity3
HDMI ports quantity2
HDMI connector typeFull-size
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portNo
S-Video inputs quantity0
USB 2.0 ports quantity1
Mini-USB 2.0 ports quantity1
Audio (L/R) in0
Serial interface typeRS-232
PC Audio inYes
PC Audio outYes
AC (power) inYes

Network

Smart TVNo
Ethernet LANNo
Ethernet LAN (RJ-45) ports0
Wi-FiNo

Storage

Card reader integratedNo

Features

Noise level31 dB
Noise level (economic mode)27 dB
On Screen Display (OSD)Yes
On Screen Display (OSD) languagesArabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Number of OSD languages22
Sleep timerYes

Multimedia

Built-in speaker(s)Yes
RMS rated power2 W

Design

Product typeStandard throw projector
Market positioningBusiness
Product colourGrey, White
PlacementDesktop
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)260 W
Power consumption (standby)0.5 W
Power consumption (max)280 W
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Auto power offYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%
Operating altitude0 - 1499 m

Weight & dimensions

Weight2.2 kg
Width294 mm
Depth218 mm
Height110 mm

Packaging content

Remote control includedYes
Cables includedAC, VGA
Quick start guideYes

Other features

RS-232 ports1
