M1 Max
Model M1 MaxPart no. M1 MAX
65 specifications
- Noise26 dB
- TypeShort throw projector
- Weight960 g
- ColourBlack, Grey
- Projector brightness500 LED lumens
- Light source typeLED
Overview
- Noise
- 26 dB
- Type
- Short throw projector
- Weight
- 960 g
- Colour
- Black, Grey
- Projector brightness
- 500 LED lumens
- Light source type
- LED
- Brand
- Viewsonic
- Category
- Data Projector
- Model
- M1 Max
- Part number
- M1 MAX
- Also known as
- Viewsonic M1 Max Short throw projector DLP 1080p (1920x1080) Black, Grey
Specifications
65 specifications in 15 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 500 LED lumens |
| Projection technology | DLP |
| Projector native resolution | 1080p (1920x1080) |
| Contrast ratio (typical) | 120000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 1:1, 4:3, 16:9 |
| Smart projector | Yes |
| Screen size compatibility | 1016 - 2540 mm (40 - 100") |
| Projection distance | 0.8 - 2.67 m |
| Number of colours | 1.07 billion colours |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -40 - 40° |
Light source
| Specification | Value |
|---|---|
| Light source type | LED |
| Service life of light source | 60000 h |
Lens system
| Specification | Value |
|---|---|
| Zoom capability | Yes |
| Zoom type | Fixed |
| Throw ratio | 1.2 |
| Offset | 100% |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
| 3D | No |
| Supported 3D formats | Frame Sequential, Side by side, Top and bottom |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DVI port | No |
| USB 2.0 Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Smart TV | Yes |
| Ethernet LAN | No |
| Wi-Fi | Yes |
| Miracast | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 26 dB |
| Noise level (economic mode) | 25 dB |
| HDCP | Yes |
| Number of OSD languages | 24 |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 6 W |
Design
| Specification | Value |
|---|---|
| Product type | Short throw projector |
| Market positioning | Portable |
| Product colour | Black, Grey |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | USB |
| Power consumption (typical) | 46 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 960 g |
| Width | 182 mm |
| Depth | 141 mm |
| Height | 62 mm |
| Package width | 235 mm |
| Package depth | 190 mm |
| Package height | 130 mm |
| Package weight | 2.02 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
