LSC601WU-ST data projector Standard throw projector 6000 ANSI lumens 3LCD WUXGA (1920x1200) Black, White
Model LSC601WU-STEAN 766907029291
56 specifications
- Noise35 dB
- TypeStandard throw projector
- Weight8.1 kg
- ColourBlack, White
- Projector brightness6000 ANSI lumens
- Light source typeLamp
Overview
- Noise
- 35 dB
- Type
- Standard throw projector
- Weight
- 8.1 kg
- Colour
- Black, White
- Projector brightness
- 6000 ANSI lumens
- Light source type
- Lamp
- Brand
- Viewsonic
- Category
- Data Projector
- Model
- LSC601WU-ST
- Part number
- LSC601WU-ST
- EAN / UPC
- 766907029291, 766907029307
- Also known as
- Viewsonic LSC601WU-ST data projector Standard throw projector 6000 ANSI lumens 3LCD WUXGA (1920x1200) Black, White
Specifications
56 specifications in 12 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 6000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 16:10, 16:9 |
| Screen size compatibility | 1397 - 4572 mm (55 - 180") |
| Projection distance | 0.521 - 1.71 m |
| Number of colours | 1.07 billion colours |
| Vertical scan range | 23 - 85 Hz |
| Keystone correction, horizontal | -15 - 15° |
| Keystone correction, vertical | -15 - 15° |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
Lens system
| Specification | Value |
|---|---|
| Fixed focal length | 6.39 mm |
| F-number (relative aperture) | 1.6 |
| Zoom capability | Yes |
| Throw ratio | 0.44 |
| Offset | 98% |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| USB 2.0 ports quantity | 1 |
| USB 2.0 Type-B ports quantity | 1 |
| Audio (L/R) in | 1 |
| Serial interface type | RS-232 |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Features
| Specification | Value |
|---|---|
| Noise level | 35 dB |
| Noise level (economic mode) | 25 dB |
| Air filter | Yes |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Education |
| Product colour | Black, White |
| LED indicators | Yes |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 345 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 8.1 kg |
| Width | 405 mm |
| Depth | 404 mm |
| Height | 164 mm |
| Package width | 510 mm |
| Package depth | 498 mm |
| Package height | 260 mm |
| Package weight | 10.9 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8528620000 |
| Pallet gross height | 170 cm |
| Pallet gross length | 100 cm |
| Pallet gross width | 120 cm |
| Products per master (outer) case | 1 pc(s) |
