Viewsonic LS800WU data projector Large venue projector 5500 ANSI lumens DLP WUXGA (1920x1200) White

Viewsonic LS800WU data projector Large venue projector 5500 ANSI lumens DLP WUXGA (1920x1200) White

Model LS800WUEAN 766907932218

73 specifications
  • TypeLarge venue projector
  • Weight11 kg
  • ColourWhite
  • Projector brightness5500 ANSI lumens
  • Light source typeLaser
  • Optical zoom1.65x
See all specifications

Overview

Type
Large venue projector
Weight
11 kg
Colour
White
Projector brightness
5500 ANSI lumens
Light source type
Laser
Optical zoom
1.65x
Brand
Viewsonic
Model
LS800WU
Part number
LS800WU
EAN / UPC
766907932218
Also known as
Viewsonic LS800WU data projector Large venue projector 5500 ANSI lumens DLP WUXGA (1920x1200) White

Specifications

73 specifications in 18 groups

Projector

Projector brightness5500 ANSI lumens
Projection technologyDLP
Projector native resolutionWUXGA (1920x1200)
Native aspect ratio16:9
Screen size compatibility762 - 7620 mm (30 - 300")
Projection distance1.3 - 12.5 m
Contrast ratio (dynamic)100000:1
Number of colours1.073 billion colours
Horizontal scan range15 - 102 kHz
Vertical scan range23 - 120 Hz

Light source

Light source typeLaser
Service life of light source20000 h
Service life of light source (economic mode)30000 h

Lens system

Optical zoom1.65x
Throw ratio1.2 - 1.9:1
Horizontal lens shift range-2.5 - 2.5%
Vertical lens shift range-2.4 - 9.2%

Video

Full HDYes
Supported graphics resolutions640 x 480 (VGA), 1920 x 1200 (WUXGA)

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity3
HDMI connector typeFull-size
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portNo
S-Video inputs quantity0
HDBaseT portYes
USB 2.0 ports quantity1
Audio (L/R) in1
Serial interface typeRS-232
PC Audio inYes
PC Audio outYes
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiNo

Storage

Card reader integratedNo

Features

On Screen Display (OSD)Yes
CertificationFCC, UL/CUL

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers2
RMS rated power10 W

Design

Product typeLarge venue projector
Product colourWhite
PlacementDesktop
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)430 W
Power consumption (standby)0.5 W
AC input voltage100-240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 90%

Weight & dimensions

Weight11 kg
Width360 mm
Depth440 mm
Height161 mm
Package width559 mm
Package depth469 mm
Package height301 mm
Package weight13.6 kg

Packaging content

Remote control includedYes
Cables includedAC, VGA
Quick start guideYes

Technical details

Compliance certificatesRoHS

Logistics data

Harmonized System (HS) code8528620000
Pallet gross height192.6 cm
Pallet gross length116 cm
Pallet gross width127 cm
Products per master (outer) case1 pc(s)

Other features

RS-232 ports1
