XP-A201U-B Short throw projector 20000 ANSI lumens 3LCD WUXGA (1920x1200) Black
Model XP-A201U-BPart no. XPA201UEAN 074000703896
52 specifications
- Noise42 dB
- TypeShort throw projector
- Weight38.7 kg
- ColourBlack
- Projector brightness20000 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 42 dB
- Type
- Short throw projector
- Weight
- 38.7 kg
- Colour
- Black
- Projector brightness
- 20000 ANSI lumens
- Light source type
- Laser
- Brand
- Sharp
- Category
- Data Projector
- Model
- XP-A201U-B
- Part number
- XPA201U
- EAN / UPC
- 074000703896, 4550556149051
- Also known as
- Sharp XP-A201U-B Short throw projector 20000 ANSI lumens 3LCD WUXGA (1920x1200) Black
Specifications
52 specifications in 13 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 20000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 16:10, 16:9 |
| Screen size compatibility | 1524 - 12700 mm (60 - 500") |
| Projection distance | 0.68 - 80.77 m |
| Horizontal scan range | 15 - 153 kHz |
| Vertical scan range | 24 - 120 Hz |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -30 - 30° |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 25000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Motorized |
| Zoom capability | Yes |
| Zoom type | Auto |
| Horizontal lens shift range | -25 - 25% |
| Vertical lens shift range | 65 - 65% |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
| 3D | No |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 2 |
| HDBaseT port | Yes |
| USB 2.0 Type-A ports quantity | 1 |
| Serial interface type | RS-232 |
| PC Audio out | Yes |
| 3G-SDI input | 1 |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Features
| Specification | Value |
|---|---|
| Noise level | 42 dB |
| Noise level (economic mode) | 34 dB |
| Certification | CE; EAC; ErP; RoHS; TUEV |
Design
| Specification | Value |
|---|---|
| Product type | Short throw projector |
| Product colour | Black |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 1530 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 38.7 kg |
| Width | 650 mm |
| Depth | 549 mm |
| Height | 262 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Remote control type | IR |
| Manual | Yes |
