NP-PV710UL-W1-13ZL data projector Standard throw projector 7100 ANSI lumens LCD DCI 4K (4096x2160) White
Model NP-PV710UL-W1-13ZLEAN 805736078244
73 specifications
- Noise40 dB
- TypeStandard throw projector
- Weight11.2 kg
- ColourWhite
- Projector brightness7100 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 40 dB
- Type
- Standard throw projector
- Weight
- 11.2 kg
- Colour
- White
- Projector brightness
- 7100 ANSI lumens
- Light source type
- Laser
- Brand
- Sharp
- Category
- Data Projector
- Model
- NP-PV710UL-W1-13ZL
- Part number
- NP-PV710UL-W1-13ZL
- EAN / UPC
- 805736078244
- Also known as
- Sharp NP-PV710UL-W1-13ZL data projector Standard throw projector 7100 ANSI lumens LCD DCI 4K (4096x2160) White
Specifications
73 specifications in 15 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 7100 ANSI lumens |
| Projection technology | LCD |
| Projector native resolution | DCI 4K (4096x2160) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 762 - 3810 mm (30 - 150") |
| Projection distance | 0.74 - 20.9 m |
| Horizontal scan range | 24 - 100 kHz |
| Vertical scan range | 50 - 85 Hz |
| Horizontal synchronization (max) | 100 kHz |
| Horizontal synchronization (min) | 24 kHz |
| Keystone correction, horizontal | 30° |
| Keystone correction, vertical | 30° |
| Vertical synchronization (max) | 0.085 kHz |
| Vertical synchronization (min) | 0.05 kHz |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Light source brightness | 8000 lm |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 24.2 - 48.6 mm |
| Zoom capability | Yes |
| Zoom type | Manual |
| Throw ratio | 1.46 - 2.95:1 |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM |
| Full HD | Yes |
| 3D | No |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 2 |
| HDMI connector type | Full-size |
| HDMI version | 2.0 |
| Component video (YPbPr/YCbCr) in | 0 |
| Composite video in | 0 |
| DVI port | No |
| HDBaseT port | Yes |
| USB 2.0 ports quantity | 1 |
| Audio (L/R) in | 0 |
| Serial interface type | RS-232 |
| AUX in | Yes |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Noise level | 40 dB |
| Noise level (economic mode) | 31 dB |
| HDCP | Yes |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Product colour | White |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 456 W |
| Power consumption (max) | 456 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage relative humidity (H-H) | 20 - 80% |
| Operating altitude | 2 - 2600 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 11.2 kg |
| Width | 503 mm |
| Depth | 411 mm |
| Height | 168 mm |
| Package width | 591 mm |
| Package depth | 591 mm |
| Package height | 259 mm |
| Package weight | 13.4 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
