NP-PA1004UL-B data projector Standard throw projector 10000 ANSI lumens LCD WUXGA (1920x1200) Black
Model NP-PA1004UL-BEAN 805736072983
68 specifications
- Display1.93 cm (0.76")
- Noise35 dB
- TypeStandard throw projector
- Weight24.4 kg
- ColourBlack
- Projector brightness10000 ANSI lumens
Overview
- Display
- 1.93 cm (0.76")
- Noise
- 35 dB
- Type
- Standard throw projector
- Weight
- 24.4 kg
- Colour
- Black
- Projector brightness
- 10000 ANSI lumens
- Brand
- Sharp
- Category
- Data Projector
- Model
- NP-PA1004UL-B
- Part number
- NP-PA1004UL-B
- EAN / UPC
- 805736072983
- Also known as
- Sharp NP-PA1004UL-B data projector Standard throw projector 10000 ANSI lumens LCD WUXGA (1920x1200) Black
Specifications
68 specifications in 13 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 10000 ANSI lumens |
| Projection technology | LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 1016 - 12700 mm (40 - 500") |
| Projection distance | 0.74 - 20.9 m |
| Horizontal synchronization (max) | 153 kHz |
| Horizontal synchronization (min) | 15 kHz |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -40 - 40° |
| Vertical synchronization (max) | 120 kHz |
| Vertical synchronization (min) | 24 kHz |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Motorized |
| Aperture range (F-F) | 2 - 6.27 |
| Throw ratio | 0.8:1 Manual Fixed Lens , 1.16 – 1.56:1 Manual Zoom Lens w/lens shift , 1.46 – 3.02:1 Manual Zoom Lens w/lens shift , 2.90 – 4.79:1 Manual Zoom Lens w/lens shift , 4.59 – 7.02:1 Manual Zoom Lens w/lens shift , 0.32:1 Ultra-Short Throw Lens / 0.79 to 1.11:1 Motorized Zoom Lens / 1.30 to 3.02:1 Motori |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM |
| Full HD | Yes |
| 3D | No |
| Supported graphics resolutions | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 4096 x 2160 |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| HDBaseT port | Yes |
| USB 2.0 ports quantity | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| Serial interface type | RS-232 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Features
| Specification | Value |
|---|---|
| Noise level | 35 dB |
| Noise level (economic mode) | 32 dB |
| HDCP | Yes |
| Composite sync | Yes |
| Separate H/V sync | Yes |
| Sync-on-green (SOG) | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Education |
| Product colour | Black |
| Placement | Ceiling, Floor |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 1.93 cm (0.76") |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 515 W |
| Power consumption (standby) | 0.8 W |
| Power consumption (max) | 635 W |
| Power consumption (PowerSave) | 0.22 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 25 - 85% |
| Storage relative humidity (H-H) | 20 - 80% |
| Operating altitude | 0 - 3650 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 24.4 kg |
| Width | 599 mm |
| Depth | 219 mm |
| Height | 490 mm |
| Package width | 735 mm |
| Package depth | 359 mm |
| Package height | 631 mm |
| Package weight | 28.9 kg |
