The Premiere 5 Full HD Touch Interaction Projector (2025)
Model SP-LPF5DSAXPart no. SP-LPF5DSAXXXUEAN 8806095651040
71 specifications
- TypeProjector module
- OSTizen
- Weight3.5 kg
- ColourWhite
- Contrast ratio (typical)1000:1
- Light source typeLaser
Overview
- Type
- Projector module
- OS
- Tizen
- Weight
- 3.5 kg
- Colour
- White
- Contrast ratio (typical)
- 1000:1
- Light source type
- Laser
- Brand
- Samsung
- Category
- Data Projector
- Model
- SP-LPF5DSAX
- Part numbers
- SP-LPF5DSAXXXU, SP-LPF5DSAXXXE
- EAN / UPC
- 8806095651040, 8806095574660
- Also known as
- Samsung The Premiere 5 Full HD Touch Interaction Projector (2025)
Specifications
71 specifications in 17 groups
Projector
| Specification | Value |
|---|---|
| Contrast ratio (typical) | 1000:1 |
| Picture processing technology | Crystal Processor 4K, Samsung Real Depth Enhancer |
| Smart projector | Yes |
| Screen size compatibility | 1524 - 2540 mm (60 - 100") |
| Contrast enhancer | Yes |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
Lens system
| Specification | Value |
|---|---|
| Focus | Auto |
Video
| Specification | Value |
|---|---|
| Analog signal format system | Not supported |
| 3D | No |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 2 |
| HDMI connector type | Micro |
| Component video (YPbPr/YCbCr) in | 0 |
| Composite video in | 0 |
| DVI port | No |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Audio (L/R) in | 0 |
| USB connector type | USB Type-C |
| Consumer Electronics Control (CEC) | Anynet+ |
| Consumer Electronics Control (CEC) support | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Web browser | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | Yes |
| Interactive input supported | Interactive pen/Touch |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Multi |
| Number of OSD languages | 27 |
| Screen mirroring | Yes |
| Adaptive contrast | Yes |
| AirPlay | Yes |
| Game mode | Yes |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | Quantum HDR, High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG) |
| Multi View | Yes |
| SmartThings app support | Yes |
| Video apps | Disney+, Netflix, Samsung TV Plus, YouTube |
| Operating system installed | Tizen |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 10 W |
| Audio output channels | 2.0 channels |
| Audio decoders | Dolby Digital Plus |
Design
| Specification | Value |
|---|---|
| Product type | Projector module |
| Market positioning | Home cinema |
| Product colour | White |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 100 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Auto power off | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.5 kg |
| Width | 240 mm |
| Depth | 182 mm |
| Height | 309 mm |
| Package width | 240 mm |
| Package depth | 182 mm |
| Package height | 309 mm |
| Package weight | 3.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Cables included | AC |
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Processor | NQP AI Processor |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Other features
| Specification | Value |
|---|---|
| HDMI | Yes |
| USB port | Yes |
