PJ UHL3660
Model PJ UHL3660Part no. 432685EAN 4961311984785
54 specifications
- Noise36 dB
- TypeUltra short throw projector
- Weight11.9 kg
- ColourWhite
- Projector brightness6500 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 36 dB
- Type
- Ultra short throw projector
- Weight
- 11.9 kg
- Colour
- White
- Projector brightness
- 6500 ANSI lumens
- Light source type
- Laser
- Brand
- Ricoh
- Category
- Data Projector
- Model
- PJ UHL3660
- Part number
- 432685
- EAN / UPC
- 4961311984785
- Also known as
- Ricoh PJ UHL3660 Ultra short throw projector 6500 ANSI lumens DLP UHD 4K (3840x2160) White
Specifications
54 specifications in 14 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 6500 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | UHD 4K (3840x2160) |
| Contrast ratio (typical) | 5000000:1 |
| Smart projector | No |
| Screen size compatibility | 2159 - 4064 mm (85 - 160") |
| Projection distance | 0.01 - 0.38 m |
| Number of colours | 1.073 billion colours |
| Keystone correction, horizontal | -15 - 15° |
| Keystone correction, vertical | -20 - 5° |
| Matrix size | 1.65 cm (0.65") |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 40000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Motorized |
| Throw ratio | 0.241 |
Video
| Specification | Value |
|---|---|
| Analog signal format system | Not supported |
| Full HD | Yes |
| 3D | No |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 3 |
| HDMI connector type | Full-size |
| HDMI version | 2.0 |
| Component video (YPbPr/YCbCr) in | 0 |
| Composite video in | 0 |
| DVI port | No |
| HDBaseT port | Yes |
| USB 2.0 ports quantity | 2 |
| Headphone outputs | 1 |
| Serial interface type | RS-232C |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Noise level | 36 dB |
| Noise level (economic mode) | 32 dB |
| HDCP | Yes |
| International Protection (IP) code | IP5X |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 3 |
| RMS rated power | 11 W |
Design
| Specification | Value |
|---|---|
| Product type | Ultra short throw projector |
| Product colour | White |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 460 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (economy mode) | 225 W |
| AC input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 11.9 kg |
| Width | 530 mm |
| Depth | 470 mm |
| Height | 139 mm |
