NEC UM352Wi-MP + NP01SW2

NEC UM352Wi-MP + NP01SW2

Model UM352Wi-MP + NP01SW2Part no. 40001056

92 specifications
  • Noise29 dB
  • TypeUltra short throw projector
  • Weight5.8 kg
  • ColourWhite
  • Projector brightness3500 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Noise
29 dB
Type
Ultra short throw projector
Weight
5.8 kg
Colour
White
Projector brightness
3500 ANSI lumens
Light source type
Lamp
Brand
NEC
Model
UM352Wi-MP + NP01SW2
Part number
40001056
Also known as
NEC UM352Wi-MP + NP01SW2 Ultra short throw projector 3500 ANSI lumens LCD WXGA (1280x800) White

Specifications

92 specifications in 17 groups

Projector

Projector brightness3500 ANSI lumens
Projection technologyLCD
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)6000:1
Native aspect ratio16:10
Supported aspect ratios16:10, 16:9
Screen size compatibility1473.2 - 2794 mm (58 - 110")
Projection distance0.1 - 0.51 m
Horizontal scan range15 - 100 kHz
Vertical scan range50 - 120 Hz
Keystone correction, horizontal-10 - 10°
Keystone correction, vertical-10 - 10°
Matrix type3-panel (p-Si TFT active)

Light source

Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)6000 h
Lamp power200 W
Lamp power (economic mode)160 W
Lamps quantity1 lamp(s)

Lens system

FocusManual
Fixed focal length4.78 mm
Aperture range (F-F)1.8 - 1.8
Zoom capabilityYes
Zoom typeManual
Zoom ratio1.4:1
Digital zoom1.4x
Throw ratio0.36:1
Offset81%

Video

Analog signal format systemNTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Full HDNo
HD-ReadyYes
3DNo
Supported graphics resolutions640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 600 (SVGA), 832 x 624, 1152 x 864 (XGA+), 1152 x 870, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity2
HDMI connector typeFull-size
Component video (YPbPr/YCbCr) in0
Composite video in0
DVI portNo
S-Video inputs quantity0
USB 2.0 ports quantity3
Audio (L/R) in1
Headphone outputs1
Microphone inYes
Serial interface typeRS-232
Mobile High-Definition Link (MHL)Yes
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiNo

Storage

Card reader integratedNo

Features

Noise level29 dB
Noise level (economic mode)28 dB
On Screen Display (OSD)Yes
Password protectionYes
CertificationCE; Gost-R; TÜV GS

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power20 W

Design

Product typeUltra short throw projector
Product colourWhite
PlacementDesktop
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)261 W
Power consumption (standby)0.5 W
Power consumption (max)326 W
Power consumption (network standby)3 W
Power consumption (economy mode)216 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Auto power offYes

Operational conditions

Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)20 - 90%

Weight & dimensions

Weight5.8 kg
Width378 mm
Depth428 mm
Height112 mm

Packaging content

Remote control includedYes
Remote control typeIR
Cables includedAC, USB, VGA
ManualYes
Mounting brackets includedYes
Quick start guideYes

Technical details

Compliance certificatesRoHS

Other features

Maximum digital resolution1920 x 1200 pixels
RS-232 ports1
