NEC PA653UL Large venue projector 6500 ANSI lumens 3LCD WUXGA (1920x1200) 3D White

NEC PA653UL Large venue projector 6500 ANSI lumens 3LCD WUXGA (1920x1200) 3D White

Model PA653ULPart no. 40001148EAN 8032976121566

68 specifications
  • Noise39 dB
  • TypeLarge venue projector
  • Weight18 kg
  • ColourWhite
  • Projector brightness6500 ANSI lumens
  • Light source typeLaser
See all specifications

Overview

Noise
39 dB
Type
Large venue projector
Weight
18 kg
Colour
White
Projector brightness
6500 ANSI lumens
Light source type
Laser
Brand
NEC
Model
PA653UL
Part numbers
40001148, 60004324
EAN / UPC
8032976121566, 5028695613065, 5057454786559, 4058154257661 +2 more
Also known as
NEC PA653UL Large venue projector 6500 ANSI lumens 3LCD WUXGA (1920x1200) 3D White

Specifications

68 specifications in 16 groups

Projector

Projector brightness6500 ANSI lumens
Projection technology3LCD
Projector native resolutionWUXGA (1920x1200)
Contrast ratio (typical)2000:1
Native aspect ratio16:10
Projection distance0.7 - 50.9 m
Horizontal scan range24 - 153 kHz
Vertical scan range48 - 120 Hz
Keystone correction, horizontal-40 - 40°
Keystone correction, vertical-40 - 40°

Light source

Light source typeLaser
Service life of light source20000 h
Lamps quantity1 lamp(s)

Lens system

Zoom capabilityYes
Horizontal lens shift range-20 - 20°
Vertical lens shift range-50 - 10°

Video

Full HDYes
3DYes
Supported graphics resolutions640 x 480 (VGA), 1920 x 1200 (WUXGA), 2048 x 1080, 2560 x 1600 (WQXGA), 4096 x 2160
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity2
HDMI connector typeFull-size
Component video (YPbPr/YCbCr) in1
DVI portNo
DisplayPorts quantity1
S-Video inputs quantity0
HDBaseT portYes
USB 2.0 ports quantity1
Headphone outputs1
Serial interface typeRS-232
PC Audio inYes
PC in (D-Sub)Yes
BNC input ports1

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiNo

Storage

Card reader integratedNo

Features

Noise level39 dB
Noise level (economic mode)33 dB
HDCPYes
On Screen Display (OSD)Yes
Password protectionYes
CertificationCE; EAC; ErP; TUEV Type Approved

Design

Product typeLarge venue projector
Product colourWhite
PlacementDesktop, Ceiling
LED indicatorsYes

Power

Power sourceAC
Power consumption (standby)0.3 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)20 - 80%

Certificates

HDBaseT certifiedYes

Weight & dimensions

Weight18 kg
Width580 mm
Depth490 mm
Height208 mm

Packaging content

Remote control includedYes
Remote control typeIR
Cables includedAC
ManualYes
Quick start guideYes

Technical details

Compliance certificatesRoHS

Other features

RS-232 ports1
