NEC PA550W Large venue projector 550 ANSI lumens LCD WXGA (1280x800) White

NEC PA550W Large venue projector 550 ANSI lumens LCD WXGA (1280x800) White

Model PA550WPart no. 60003085EAN 8057360378524

81 specifications
  • ConnectivityWired
  • Noise38 dB
  • TypeLarge venue projector
  • Weight7.7 kg
  • ColourWhite
  • Projector brightness550 ANSI lumens
See all specifications

Overview

Connectivity
Wired
Noise
38 dB
Type
Large venue projector
Weight
7.7 kg
Colour
White
Projector brightness
550 ANSI lumens
Brand
NEC
Model
PA550W
Part number
60003085
EAN / UPC
8057360378524, 172302796667, 786333002064, 805736037852 +2 more
Also known as
NEC PA550W Large venue projector 550 ANSI lumens LCD WXGA (1280x800) White

Specifications

81 specifications in 17 groups

Projector

Projector brightness550 ANSI lumens
Projection technologyLCD
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)2000:1
Native aspect ratio16:10
Supported aspect ratios4:3, 16:10
Screen size compatibility635 - 12700 mm (25 - 500")
Projection distance0.74 - 20.9 m
Horizontal scan range15 - 108 kHz
Vertical scan range48 - 120 Hz
Keystone correction, horizontal±40°
Keystone correction, vertical±30°
Matrix size1.91 cm (0.75")

Light source

Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)4000 h
Lamp power330 W
Lamp power (economic mode)264 W
Lamps quantity1 lamp(s)

Lens system

FocusManual
Focal length range24.4 - 32.5 mm
Aperture range (F-F)1.7 - 2.2
Zoom capabilityYes
Zoom typeManual
Zoom ratio2.0:1
Throw ratio1.5 - 3.0:1
Horizontal lens shift range-0.3 - 3°
Vertical lens shift range-0.1 - 5°

Video

Analog signal format systemNTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Full HDNo
3DNo
Supported graphics resolutions1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080)
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p

Ports & interfaces

VGA (D-Sub) ports quantity3
HDMI ports quantity1
Component video (YPbPr/YCbCr) in1
Composite video in0
DVI portNo
DisplayPorts quantity1
S-Video inputs quantity1
USB 2.0 ports quantity1
Audio (L/R) in1
Headphone outputs1
Serial interface typeRS-232
BNC input ports1
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1

Storage

Card reader integratedNo

Features

Noise level38 dB
Noise level (economic mode)31 dB
HDCPYes
CertificationUL, FCC, CSA, NOM

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power10 W

Design

Product typeLarge venue projector
Product colourWhite
PlacementDesktop

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)464 W
Power consumption (standby)16 W
Power consumption (PowerSave)0.2 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Software

Mac operating systems supportedYes

Operational conditions

Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)20 - 80%

Weight & dimensions

Weight7.7 kg
Width499 mm
Depth366 mm
Height164 mm

Packaging content

Remote control includedYes
Batteries includedYes
Cables includedAC
ManualYes
Quick start guideYes

Other features

Connectivity technologyWired
RS-232 ports1
