NEC P502HL Standard throw projector 5000 ANSI lumens DLP 1080p (1920x1080) 3D White

NEC P502HL Standard throw projector 5000 ANSI lumens DLP 1080p (1920x1080) 3D White

Model P502HLPart no. 60004368EAN 5028695613041

96 specifications
  • Noise39 dB
  • TypeStandard throw projector
  • Weight8.8 kg
  • ColourWhite
  • Projector brightness5000 ANSI lumens
  • Light source typeLaser
See all specifications

Overview

Noise
39 dB
Type
Standard throw projector
Weight
8.8 kg
Colour
White
Projector brightness
5000 ANSI lumens
Light source type
Laser
Brand
NEC
Model
P502HL
Part numbers
60004368, 60003694
EAN / UPC
5028695613041, 4058154002469, 5028695611948, 8592978071059
Also known as
NEC P502HL Standard throw projector 5000 ANSI lumens DLP 1080p (1920x1080) 3D White

Specifications

96 specifications in 16 groups

Projector

Projector brightness5000 ANSI lumens
Projection technologyDLP
Projector native resolution1080p (1920x1080)
Contrast ratio (typical)150000:1
Native aspect ratio4:3
Supported aspect ratios16:9
Screen size compatibility762 - 7620 mm (30 - 300")
Projection distance0.8 - 14.2 m
Number of colours16.78 million colours
Horizontal scan range50 - 120 kHz
Vertical scan range15 - 100 Hz
Horizontal synchronization (max)100 kHz
Horizontal synchronization (min)15 kHz
Keystone correction, horizontal- 25 - 25°
Keystone correction, vertical- 30 - 30°
Matrix size1.68 cm (0.66")
Matrix typeDMD

Light source

Light source typeLaser
Service life of light source20000 h
Lamps quantity1 lamp(s)

Lens system

FocusManual
Focal length range18.2 - 31.1 mm
Aperture range (F-F)2 - 2.5
Zoom capabilityYes
Zoom ratio1.7:1
Throw ratio1.24 - 2.11:1
Horizontal lens shift range0.28 - -0.28°
Vertical lens shift range0.62 - 0.62°
Offset62%

Video

Analog signal format systemNTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Full HDYes
3DYes
3D ReadyYes
Supported graphics resolutions1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity2
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portNo
HDBaseT portYes
USB 2.0 ports quantity3
Audio (L/R) in1
Headphone outputs1
Microphone inYes
Serial interface typeRS-232
PC in (D-Sub)Yes
USB connector typeUSB Type-A, USB Type-B
Progressive scan outputYes
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiYes
BluetoothNo

Storage

Card reader integratedNo

Features

Noise level39 dB
Noise level (economic mode)33 dB
HDCPYes
Preset modesCinema, Presentation, sRGB
On Screen Display (OSD)Yes
CertificationUSA UL 1950 FCC, CSA 950 (C-UL), NOM

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power20 W

Design

Product typeStandard throw projector
Product colourWhite
PlacementDesktop
Cable lock slotYes
Cable lock slot typeKensington
LED indicatorsYes

Power

Power sourceAC/Battery
Power consumption (standby)0.3 W
Power consumption (max)442 W
Power consumption (network standby)2 W
Power consumption (economy mode)347 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Auto power offYes

Software

Windows operating systems supportedYes
Mac operating systems supportedYes

Operational conditions

Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)20 - 80%

Weight & dimensions

Weight8.8 kg
Width469 mm
Depth365 mm
Height137 mm

Packaging content

Remote control includedYes
Remote control typeIR
Batteries includedYes
Cables includedAC, VGA
ManualYes
Quick start guideYes

Other features

Maximum analog resolution1920 x 1200 pixels
Maximum digital resolution1920 x 1080 pixels
RS-232 ports1
