NP-PE506WL data projector Standard throw projector 5200 ANSI lumens LCD WXGA (1280x800) White
Model NP-PE506WLEAN 805736076745
65 specifications
- Noise37 dB
- TypeStandard throw projector
- Weight7.58 kg
- ColourWhite
- Projector brightness5200 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 37 dB
- Type
- Standard throw projector
- Weight
- 7.58 kg
- Colour
- White
- Projector brightness
- 5200 ANSI lumens
- Light source type
- Laser
- Brand
- NEC
- Category
- Data Projector
- Model
- NP-PE506WL
- Part number
- NP-PE506WL
- EAN / UPC
- 805736076745
- Also known as
- NEC NP-PE506WL data projector Standard throw projector 5200 ANSI lumens LCD WXGA (1280x800) White
Specifications
65 specifications in 16 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 5200 ANSI lumens |
| Projection technology | LCD |
| Projector native resolution | WXGA (1280x800) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Projection distance | 0.8 - 13.5 m |
| Horizontal scan range | 15 - 100 kHz |
| Vertical scan range | 24 - 85 Hz |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
| Matrix size | 1.63 cm (0.64") |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 17.42 - 28.99 mm |
| Aperture range (F-F) | 1.7 - 2.2 |
| Zoom type | Manual |
| Throw ratio | 1.2 - 2.1:1 |
Video
| Specification | Value |
|---|---|
| Supported graphics resolutions | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA) |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| DVI port | No |
| Audio (L/R) in | 0 |
| Serial interface type | RS-232 |
| PC Audio in | Yes |
| PC Audio out | Yes |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Noise level | 37 dB |
| Noise level (economic mode) | 27 dB |
| HDCP | Yes |
| Certification | USA: UL (UL60950-1/UL62368-1) FCC Part15 Class B, Canada: CAN/CSA (62368-1-14) ICES-003 Issue 7 |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 16 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Product colour | White |
| Placement | Desktop |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 212 W |
| Power consumption (standby) | 2 W |
| Power consumption (max) | 330 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Auto power off | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 88% |
| Storage relative humidity (H-H) | 20 - 88% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 7.58 kg |
| Width | 404 mm |
| Depth | 358 mm |
| Height | 137 mm |
| Package width | 510 mm |
| Package depth | 500 mm |
| Package weight | 9.58 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85286200 |
