NEC NP-M323X data projector Standard throw projector 3200 ANSI lumens DLP XGA (1024x768) White

NEC NP-M323X data projector Standard throw projector 3200 ANSI lumens DLP XGA (1024x768) White

Model NP-M323XEAN 805736059137

72 specifications
  • Noise33 dB
  • TypeStandard throw projector
  • Weight3.5 kg
  • ColourWhite
  • Projector brightness3200 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Noise
33 dB
Type
Standard throw projector
Weight
3.5 kg
Colour
White
Projector brightness
3200 ANSI lumens
Light source type
Lamp
Brand
NEC
Model
NP-M323X
Part number
NP-M323X
EAN / UPC
805736059137
Also known as
NEC NP-M323X data projector Standard throw projector 3200 ANSI lumens DLP XGA (1024x768) White

Specifications

72 specifications in 16 groups

Projector

Projector brightness3200 ANSI lumens
Projection technologyDLP
Projector native resolutionXGA (1024x768)
Contrast ratio (typical)10000:1
Native aspect ratio4:3
Supported aspect ratios16:9, 4:3
Screen size compatibility762 - 7620 mm (30 - 300")
Projection distance0.9 - 15.97 m
Horizontal scan range15 - 100 kHz
Vertical scan range50 - 120 Hz
Keystone correction, horizontal± 25°
Keystone correction, vertical± 30°
Matrix size1.4 cm (0.55")
Matrix typeDMD

Light source

Light source typeLamp
Service life of light source3500 h
Service life of light source (economic mode)8000 h
Lamp power225 W
Lamp power (economic mode)150 W

Lens system

FocusManual
Focal length range17.09 - 29.05 mm
Aperture range (F-F)2.4 - 3.1
Zoom ratio1.7:1
Throw ratio1.5 - 2.5:1

Video

Analog signal format systemSECAM, NTSC, PAL, NTSC 4.43, PAL 60, PAL M, PAL N
Full HDNo
3DNo
Supported graphics resolutions1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes480i, 576p, 1080i, 480p, 1080p, 720p, 576i

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity2
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portNo
S-Video inputs quantity0
USB 2.0 ports quantity1
Audio (L/R) in1
Microphone inYes
Serial interface typeRS-232
PC in (D-Sub)Yes
AC (power) inYes

Network

Ethernet LANNo
Wi-FiNo

Storage

Card reader integratedNo

Features

Noise level33 dB
Noise level (economic mode)27 dB
HDCPYes
CertificationUL, CSA, FCC, ICES

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power20 W

Design

Product typeStandard throw projector
Market positioningPortable
Product colourWhite
PlacementDesktop
LED indicatorsYes

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)283 W
Power consumption (standby)2.6 W
Power consumption (PowerSave)0.2 W
Power consumption (economy mode)186 W
AC input voltage100 - 240 V

Operational conditions

Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)20 - 80%

Weight & dimensions

Weight3.5 kg
Width368 mm
Depth292 mm
Height108 mm

Packaging content

Remote control includedYes

Other features

RS-232 ports1
