PowerLite L690SU Short throw projector 6200 ANSI lumens 3LCD WUXGA (1920x1200) White
Model L690SUPart no. V11HB31020EAN 010343988996
84 specifications
- Display1.7 cm (0.67")
- Noise34 dB
- TypeShort throw projector
- Weight8.9 kg
- ColourWhite
- Projector brightness6200 ANSI lumens
Overview
- Display
- 1.7 cm (0.67")
- Noise
- 34 dB
- Type
- Short throw projector
- Weight
- 8.9 kg
- Colour
- White
- Projector brightness
- 6200 ANSI lumens
- Brand
- Epson
- Category
- Data Projector
- Model
- L690SU
- Part number
- V11HB31020
- EAN / UPC
- 010343988996
- Also known as
- Epson PowerLite L690SU Short throw projector 6200 ANSI lumens 3LCD WUXGA (1920x1200) White
Specifications
84 specifications in 17 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 6200 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 5000000:1 |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 16:10, 16:6, 21:9 |
| Screen size compatibility | 1524 - 10160 mm (60 - 400") |
| Projection distance | 1.02 - 11.89 m |
| Projection distance (wide) | 1 - 7 m |
| Projection distance (tele) | 1.8 - 11.9 m |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 4340 ANSI lumens |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 11.6 - 19.9 mm |
| Aperture range (F-F) | 1.7 - 2.1 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Zoom ratio | 1.2:1 |
| Throw ratio | 0.79 - 1.36:1 |
| Horizontal lens shift range | -20 - 20% |
| Vertical lens shift range | -50 - 50% |
Video
| Specification | Value |
|---|---|
| Analog signal format system | Not supported |
| Full HD | Yes |
| 3D | No |
| Video colour modes | Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 2 |
| DVI port | No |
| HDBaseT port | Yes |
| USB 2.0 ports quantity | 3 |
| USB 2.0 Type-A ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Serial interface type | RS-232C |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Miracast | Yes |
| Apple AirPlay 2 support | Yes |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 34 dB |
| Noise level (economic mode) | 25 dB |
| HDCP | Yes |
| Preset modes | Cinema, Dynamic, Presentation |
| On Screen Display (OSD) | Yes |
| HDCP version | 2.3 |
| Password protection | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Product type | Short throw projector |
| Market positioning | Education |
| Product colour | White |
| Placement | Ceiling, Desktop |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 1.7 cm (0.67") |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 336 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (max) | 399 W |
| Power consumption (economy mode) | 233 W |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 8.9 kg |
| Width | 440 mm |
| Depth | 362 mm |
| Height | 151 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | Power |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 3 year(s) |
Other features
| Specification | Value |
|---|---|
| RS-232C | Yes |
| Supported network protocols | HTTPS, SNMP, ESC/VP.net, PJLink |
