EpiqVision Mini EF21
Model EpiqVision Mini EF21Part no. V11HB35320EAN 010343990043
61 specifications
- Noise23 dB
- TypeStandard throw projector
- Weight2.3 kg
- ColourBlack, Green
- Projector brightness1000 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 23 dB
- Type
- Standard throw projector
- Weight
- 2.3 kg
- Colour
- Black, Green
- Projector brightness
- 1000 ANSI lumens
- Light source type
- Laser
- Brand
- Epson
- Category
- Data Projector
- Model
- EpiqVision Mini EF21
- Part number
- V11HB35320
- EAN / UPC
- 010343990043
- Also known as
- Epson EpiqVision Mini EF21 Standard throw projector 1000 ANSI lumens 3LCD 1080p (1920x1080) Black, Green
Specifications
61 specifications in 17 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 1000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | 1080p (1920x1080) |
| Contrast ratio (typical) | 5000000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 16:9 |
| Smart projector | Yes |
| Screen size compatibility | 762 - 3810 mm (30 - 150") |
| Number of colours | 16.7 million colours |
| Vertical scan range | 200 - 240 Hz |
| Colour light output | 1000 ANSI lumens |
| Matrix size | 1.57 cm (0.62") |
| White light output | 1000 ANSI lumens |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
Lens system
| Specification | Value |
|---|---|
| Fixed focal length | 13.9 mm |
| F-number (relative aperture) | 2 |
| Throw ratio | 1.00 - 1.82:1 |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
| 3D | No |
| Video colour modes | Cinema, Dynamic, Natural, Bright cinema, Vivid |
| Video processing | 8 bit |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| USB 2.0 Type-A ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Smart TV | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 23 dB |
| Noise level (economic mode) | 19 dB |
| HDCP | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Home cinema |
| Product colour | Black, Green |
| Placement | Desktop, Floor, TV cabinet |
| Cable lock slot | Yes |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 109 W |
| Power consumption (economy mode) | 80 W |
| AC input frequency | 50 - 60 Hz |
Supplier features
| Specification | Value |
|---|---|
| Number of pieces | 1 pc(s) |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 60% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.3 kg |
| Width | 197 mm |
| Depth | 191 mm |
| Height | 113 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 5 year(s) |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
