EMP-7900NL XGA 4000ALu 33db noLens
Model EMP-7900NL XGA 4000ALu 33db noLensPart no. V11H170940EAN 8715946256399
43 specifications
- Resolution786 x 432 pixels
- Weight5.6 kg
- Projector brightness4000, 3000
- Light source typeLamp
- Country of originChina
- Market positioningHome cinema
Overview
- Resolution
- 786 x 432 pixels
- Weight
- 5.6 kg
- Projector brightness
- 4000, 3000
- Light source type
- Lamp
- Country of origin
- China
- Market positioning
- Home cinema
- Brand
- Epson
- Category
- Data Projector
- Model
- EMP-7900NL XGA 4000ALu 33db noLens
- Part numbers
- V11H170940, V11H170940DA, V11H170940DB
- EAN / UPC
- 8715946256399, 8715946265513
- Also known as
- Epson EMP-7900NL
Specifications
43 specifications in 9 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 4000, 3000 |
| Projector native resolution | XGA (1024x768) |
| Contrast ratio (typical) | 700:1 |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Number of colours | 16.78 million colours |
| Uniformity | 90% |
| Horizontal scan range | 15 - 107 kHz |
| Vertical scan range | 50 - 120 Hz |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 2000 h |
| Lamp type | UHE |
| Lamp power | 250 W |
Features
| Specification | Value |
|---|---|
| Country of origin | China |
Design
| Specification | Value |
|---|---|
| Market positioning | Home cinema |
Display
| Specification | Value |
|---|---|
| Display resolution | 786 x 432 pixels |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 5.6 kg |
| Package width | 410 mm |
| Package depth | 510 mm |
| Package height | 300 mm |
| Package weight | 8.65 kg |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Pallet gross height | 100 cm |
| Pallet gross width | 120 cm |
| Pallet length (UK) | 165 cm |
| Products per pallet | 10 pc(s) |
| Products per pallet (UK) | 20 pc(s) |
| Products per pallet layer | 2 pc(s) |
| Products per pallet layer (UK) | 4 pc(s) |
Other features
| Specification | Value |
|---|---|
| Aspect ratio | 4:3 |
| Audio input | Stereo mini jack x 1, RCA x 2 |
| Audio output | Stereo mini jack |
| Audio system | 5W Monaural |
| Dimensions (WxDxH) | 325 x 419 x 117 mm |
| Lens system | ELPLW03, ELPLM03, ELPLL05 |
| Power requirements | 100 - 240VAC 3.6 - 1.6A 50/60Hz |
| Resolution | 1024 x 768 pixels |
| Tilt angle range | -4 - 12° |
| Video in | Mini D-sub 15pin x 1, 5-BNC x 1 |
| Video out | Mini D-sub 15pin x1 |
| Digital keystone correction | 10:0 |
| I/O ports | RJ45 x 1 USB1.1 |
| Recommended operating temperature range (T-T) | 5 - 40 °C |
