EH-QL7000W
Model EH-QL7000WPart no. V11HB46980EAN 8715946733890
62 specifications
- Noise33 dB
- Weight21.1 kg
- ColourWhite
- Projector brightness10000 ANSI lumens
- Light source typeLaser
- Focal length rangeVaries by lens
Overview
- Noise
- 33 dB
- Weight
- 21.1 kg
- Colour
- White
- Projector brightness
- 10000 ANSI lumens
- Light source type
- Laser
- Focal length range
- Varies by lens
- Brand
- Epson
- Category
- Data Projector
- Model
- EH-QL7000W
- Part number
- V11HB46980
- EAN / UPC
- 8715946733890
- Also known as
- Epson EH-QL7000W
Specifications
62 specifications in 12 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 10000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | UHD 4K (3840x2160) |
| Contrast ratio (typical) | 3000:1 |
| Native aspect ratio | 16:9 |
| Contrast ratio (dynamic) | 5000000:1 |
| Number of colours | 1.07 billion colours |
| Vertical scan range | 384 - 480 Hz |
| Keystone correction, horizontal | ±30° |
| Keystone correction, vertical | ±45° |
| Heat dissipation | 2081 BTU/h |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 20000 h |
Lens system
| Specification | Value |
|---|---|
| Focal length range | Varies by lens |
| Zoom ratio | 1.61:1 |
| Throw ratio | 1.52 - 2.47:1, Varies by lens |
| Lens position memory | 10 |
| Interchangeable lens | Yes |
Video
| Specification | Value |
|---|---|
| 3D | No |
| Colour modes (2D) | Cinema, Dynamic, Natural, Vivid |
| Video colour modes | Cinema, Dynamic, Natural, Vivid |
| Video processing | 10 bit |
Features
| Specification | Value |
|---|---|
| Noise level | 33 dB |
| Noise level (economic mode) | 26 dB |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Placement | Ceiling, Desktop |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 21.1 kg |
| Width | 568 mm |
| Depth | 568 mm |
| Height | 192 mm |
| Package width | 690 mm |
| Package depth | 860 mm |
| Package height | 365 mm |
| Package weight | 29.7 kg |
Technical details
| Specification | Value |
|---|---|
| Other features | A/V mute, Direct Power on/off, Frame interpolation, Horizontal and vertical keystone correction, Lens position memory, OSD copy function, Quick Corner, Super resolution |
| Power consumption | 612 Watt (Normal On-Mode), 318 Watt (Eco On-Mode), 0.5 Watt (Energy saving standby) |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Pallet gross height | 197.5 cm |
| Pallet gross length | 120 cm |
| Pallet gross width | 80 cm |
| Pallet height (UK) | 197.5 cm |
| Pallet length (UK) | 120 cm |
| Products per pallet | 5 pc(s) |
| Products per pallet (UK) | 5 pc(s) |
| Products per pallet layer | 1 pc(s) |
| Products per pallet layer (UK) | 1 pc(s) |
Other features
| Specification | Value |
|---|---|
| Interface | USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Jack plug out, HDMI (HDCP 2.3) (2x) |
| Security features | Kensington lock |
| Supported network protocols | IPv6, PJLink |
| Option type | Air filter, Ceiling mount, Safety wire set, Suspension adapter |
| Box contents | Cable cover, Power cable, Remote control incl. batteries, User guide, Warranty card |
| Control panel | 1.04 inch with C2 Fine |
