Pro Cinema EH-QL3000B
Model EH-QL3000BPart no. V11HB34880EAN 8715946733869
96 specifications
- Noise28 dB
- TypeUltra short throw projector
- Weight21.1 kg
- ColourBlack
- Projector brightness6000 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 28 dB
- Type
- Ultra short throw projector
- Weight
- 21.1 kg
- Colour
- Black
- Projector brightness
- 6000 ANSI lumens
- Light source type
- Laser
- Brand
- Epson
- Category
- Data Projector
- Model
- EH-QL3000B
- Part number
- V11HB34880
- EAN / UPC
- 8715946733869
- Also known as
- Epson Pro Cinema EH-QL3000B
Specifications
96 specifications in 17 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 6000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | UHD 4K (3840x2160) |
| Contrast ratio (typical) | 3000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 4:3, 5:4, 21:9, 1.9:1 |
| Smart projector | No |
| Screen size compatibility | 1524 - 7620 mm (60 - 300") |
| Contrast ratio (dynamic) | 5000000:1 |
| Number of colours | 1.07 billion colours |
| Vertical scan range | 384 - 480 Hz |
| Keystone correction, horizontal | ±30° |
| Keystone correction, vertical | ±45° |
| Matrix size | 2.64 cm (1.04") |
| Heat dissipation | 1486 BTU/h |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 20000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Motorized |
| Focal length range | Varies by lens |
| Zoom ratio | 1.61:1 |
| Throw ratio | 1.52 - 2.47:1, Varies by lens |
| Lens position memory | 10 |
| Interchangeable lens | Yes |
Video
| Specification | Value |
|---|---|
| Analog signal format system | Not supported |
| Full HD | Yes |
| 3D | No |
| Colour modes (2D) | Cinema, Dynamic, Natural, Vivid |
| Supported graphics resolutions | 720 x 480, 720 x 576, 1600 x 1200, 2560 x 1080, 4096 x 2160 |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
| Video colour modes | Cinema, Dynamic, Natural, Vivid |
| Video processing | 10 bit |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| DVI port | No |
| USB 2.0 ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Headphone outputs | 1 |
| Serial interface type | RS-232C |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 28 dB |
| Noise level (economic mode) | 26 dB |
| HDCP | Yes |
| Air filter | Yes |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
Design
| Specification | Value |
|---|---|
| Product type | Ultra short throw projector |
| Market positioning | Home cinema |
| Product colour | Black |
| Placement | Ceiling, Desktop |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 437 W |
| Power consumption (economy mode) | 346 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 21.1 kg |
| Width | 568 mm |
| Depth | 568 mm |
| Height | 192 mm |
| Package width | 690 mm |
| Package depth | 865 mm |
| Package height | 365 mm |
| Package weight | 29.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC |
Technical details
| Specification | Value |
|---|---|
| Other features | A/V mute, Direct Power on/off, Frame interpolation, Horizontal and vertical keystone correction, Lens position memory, OSD copy function, Quick Corner, Super resolution |
| Power consumption | 437 Watt (Normal On-Mode), 346 Watt (Eco On-Mode), 0.5 Watt (Energy saving standby) |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Pallet gross height | 197.5 cm |
| Pallet gross length | 120 cm |
| Pallet gross width | 80 cm |
| Pallet height (UK) | 197.5 cm |
| Pallet length (UK) | 120 cm |
| Products per pallet | 5 pc(s) |
| Products per pallet (UK) | 5 pc(s) |
| Products per pallet layer | 1 pc(s) |
| Products per pallet layer (UK) | 1 pc(s) |
Other features
| Specification | Value |
|---|---|
| Interface | USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Jack plug out, HDMI (HDCP 2.3) (2x) |
| Security features | Kensington lock |
| Supported network protocols | IPv6, PJLink |
| Option type | Air filter, Ceiling mount, Safety wire set, Suspension adapter |
| Box contents | Cable cover, Power cable, Remote control incl. batteries, User guide, Warranty card |
| Control panel | 1.04 inch with C2 Fine |
