Epson EB685WI Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White

Epson EB685WI Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White

Model EB685WIPart no. V11H741553EAN 9314020620874

72 specifications
  • Noise35 dB
  • TypeUltra short throw projector
  • Weight5.9 kg
  • ColourWhite
  • Projector brightness3500 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Noise
35 dB
Type
Ultra short throw projector
Weight
5.9 kg
Colour
White
Projector brightness
3500 ANSI lumens
Light source type
Lamp
Brand
Epson
Model
EB685WI
Part number
V11H741553
EAN / UPC
9314020620874
Also known as
Epson EB685WI Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White

Specifications

72 specifications in 15 groups

Projector

Projector brightness3500 ANSI lumens
Projection technology3LCD
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)14000:1
Native aspect ratio16:10
Supported aspect ratios16:10
Screen size compatibility1524 - 2540 mm (60 - 100")
Projection distance (wide)0 - 0.4 m
Projection distance (tele)0 - 0.6 m
Number of colours1.073 billion colours
Projector brightness (economic mode)2900 ANSI lumens
Colour light output3500 ANSI lumens
Keystone correction, horizontal-3 - 3°
Keystone correction, vertical-3 - 3°
Matrix size1.5 cm (0.59")
Vertical synchronization (max)0.12 kHz
Vertical synchronization (min)0.1 kHz
White light output3500 ANSI lumens

Light source

Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Lamp power250 W

Lens system

FocusManual
Zoom ratio1.35:1
Throw ratio0.28:1

Video

Full HDNo
3DNo

Ports & interfaces

VGA (D-Sub) ports quantity3
HDMI ports quantity3
Composite video in1
DVI portNo
S-Video inputs quantity1
USB 2.0 ports quantity3
Audio (L/R) in1
Headphone outputs1
Microphone inYes
Serial interface typeRS-232C
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1

Storage

Card reader integratedNo

Features

Noise level35 dB
Noise level (economic mode)30 dB

Multimedia

Built-in speaker(s)Yes
RMS rated power16 W

Design

Product typeUltra short throw projector
Market positioningUlta short throw
Product colourWhite
PlacementWall
Cable lock slotYes
Cable lock slot typeKensington
LED indicatorsYes

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)354 W
Power consumption (standby)0.39 W
Power consumption (economy mode)310 W
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Weight5.9 kg
Width367 mm
Depth400 mm
Height149 mm
Package width335 mm
Package depth730 mm
Package height490 mm

Packaging content

Remote control includedNo
ManualYes
