Epson EB-Z9870U

Epson EB-Z9870U

Model EB-Z9870UPart no. V11H611040EAN 8715946541310

98 specifications
  • Display2.62 cm (1.03")
  • Noise39 dB
  • TypeLarge venue projector
  • Weight26 kg
  • ColourWhite
  • Projector brightness8700 ANSI lumens
See all specifications

Overview

Display
2.62 cm (1.03")
Noise
39 dB
Type
Large venue projector
Weight
26 kg
Colour
White
Projector brightness
8700 ANSI lumens
Brand
Epson
Model
EB-Z9870U
Part number
V11H611040
EAN / UPC
8715946541310
Also known as
Epson EB-Z9870U

Specifications

98 specifications in 17 groups

Projector

Projector brightness8700 ANSI lumens
Projection technology3LCD
Projector native resolutionWUXGA (1920x1200)
Contrast ratio (typical)15000:1
Native aspect ratio16:10
Supported aspect ratios4:3, 16:9
Screen size compatibility1524 - 12700 mm (60 - 500")
Projection distance1.52 - 12.7 m
Projection distance (wide)2 - 17.2 m
Projection distance (tele)3.3 - 27.8 m
Contrast ratio (dynamic)15000:1
Number of colours1.073 billion colours
Projector brightness (economic mode)6600 ANSI lumens
Uniformity90%
Keystone correction, horizontal±30°
Keystone correction, vertical±30°

Light source

Light source typeLamp
Service life of light source2500 h
Service life of light source (economic mode)4000 h
Lamp typeUHE
Lamp power380 W

Lens system

FocusMotorized
Focal length range36 - 57.5 mm
Aperture range (F-F)1.65 - 2.51
Zoom capabilityYes
Zoom ratio1.61:1
Throw ratio1.57 - 2.56:1
Horizontal lens shift range-30 - 30°
Vertical lens shift range-30 - 30°
Horizontal lens shift range-18 - -18%
Vertical lens shift range-60 - -60%

Video

Full HDNo
3DNo
Video colour modesDICOM simulation mode, Dynamic, Photo, Presentation, sRGB, Theatre

Ports & interfaces

VGA (D-Sub) ports quantity1
HDMI ports quantity1
DVI portYes
S-Video inputs quantity1
USB 2.0 ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Serial interface typeRS-232
USB connector typeUSB Type-A
BNC input ports1

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiYes
BluetoothNo

Features

Noise level39 dB
Noise level (economic mode)35 dB
HDCPNo
Country of originChina

Multimedia

Built-in speaker(s)No

Design

Product typeLarge venue projector
Product colourWhite
PlacementDesktop
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayYes
Display diagonal2.62 cm (1.03")

Power

Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Voltage tolerance10%

Operational conditions

Operating temperature (T-T)5 - 50 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Weight26 kg
Width741 mm
Depth534 mm
Height197 mm
Package width655 mm
Package depth890 mm
Package height375 mm
Package weight33.7 kg

Packaging content

Remote control includedNo
Remote control typeIR
Cables includedHDMI
ManualYes
Bundled softwareEasyMP Monitor, EasyMP Multi PC Projection, EasyMP Network Projection

Technical details

Power consumption948 Watt (Normal Peak-mode), 788 Watt (Eco Peak-Mode), 0.37 Watt (Energy saving standby)

Logistics data

Quantity per pack1 pc(s)
Pallet gross height161 cm
Pallet gross length120 cm
Pallet gross width80 cm
Pallet height (UK)161 cm
Pallet length (UK)120 cm
Pallet width (UK)100 cm
Products per pallet4 pc(s)
Products per pallet (UK)4 pc(s)
Products per pallet layer1 pc(s)
Products per pallet layer (UK)1 pc(s)

Other features

InterfaceUSB 1.0-A, USB 2.0 Type B (Service Only), RS-232C, WLAN, VGA in, VGA out, DVI in, HDMI in, Composite in, Component in, BNC in (6x), S-Video in, HDBaseT, HD-SDI
RS-232 ports1
Security featuresKensington lock, Security cable hole
Option typeDocument camera
Box contentsComputer cable, HDMI Cable Clamp, Power cable, Remote control incl. batteries, User's Manual Set
Control panel1.03 inch with C2 Fine
