EB-PU2116W
Model EB-PU2116WPart no. V11HA64940EAN 8715946703176
109 specifications
- Noise38 dB
- TypeLarge venue projector
- Weight24.3 kg
- ColourWhite
- Projector brightness16000 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 38 dB
- Type
- Large venue projector
- Weight
- 24.3 kg
- Colour
- White
- Projector brightness
- 16000 ANSI lumens
- Light source type
- Laser
- Brand
- Epson
- Category
- Data Projector
- Model
- EB-PU2116W
- Part numbers
- V11HA64940, V11HA64920
- EAN / UPC
- 8715946703176, 010343968936
- Also known as
- Epson EB-PU2116W
Specifications
109 specifications in 19 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 16000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 2000:1 |
| Native aspect ratio | 16:10 |
| Smart projector | No |
| Screen size compatibility | 1524 - 25400 mm (60 - 1000") |
| Contrast ratio (dynamic) | 5000000:1 |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 11200 ANSI lumens |
| Colour light output | 16000 ANSI lumens |
| Keystone correction, horizontal | 18° |
| Keystone correction, vertical | 60° |
| Matrix size | 2.62 cm (1.03") |
| White light output | 16000 ANSI lumens |
| Heat dissipation | 3682 BTU/h |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Light source brightness | 16000 lm |
Lens system
| Specification | Value |
|---|---|
| Focus | Motorized |
| Focal length range | Varies by lens |
| Zoom capability | Yes |
| Zoom type | Auto |
| Zoom ratio | 1.6:1 |
| Throw ratio | 0.35 - 7.41:1, Varies by lens |
| Horizontal lens shift range | -18 - -18% |
| Vertical lens shift range | -60 - -60% |
| Lens position memory | 10 |
| Interchangeable lens | Yes |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
| 3D | No |
| Video colour modes | BT.709, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation |
| Video processing | 10 bit |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DVI port | Yes |
| HDBaseT port | Yes |
| Service port type | USB Type-B |
| USB 2.0 ports quantity | 2 |
| USB 2.0 Type-A ports quantity | 2 |
| Serial interface type | RS-232C |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 38 dB |
| Noise level (economic mode) | 34 dB |
| Projection modes | Ceiling |
| On Screen Display (OSD) | Yes |
| Country of origin | China |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG) |
| Password protection | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
Design
| Specification | Value |
|---|---|
| Product type | Large venue projector |
| Product colour | White |
| Placement | Ceiling, Desktop, Flying frame |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 1083 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (economy mode) | 773 W |
| AC input voltage | 200 - 240 V |
| AC input frequency | 50 - 60 Hz |
Software
| Specification | Value |
|---|---|
| Software support | via: AMX, Crestron (Network), Extron |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 24.3 kg |
| Width | 586 mm |
| Depth | 492 mm |
| Height | 218 mm |
| Package width | 715 mm |
| Package depth | 790 mm |
| Package height | 335 mm |
| Package weight | 30.6 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC |
| Manual | Yes |
| WLAN adapter included | Yes |
| Warranty card | Yes |
| Packaging content | Cable cover, Lens connector cap, Power cable, Remote control incl. batteries, User manual, Warranty document |
| Bundled software | Epson Creative Projection, Epson Projector Config Tool, Epson Projector Content Manager, Epson Projector Management, Epson Projector Professional Tool |
Technical details
| Specification | Value |
|---|---|
| Other features | 21:9 aspect ratio support, 4K enhancement, A/V mute, Auto Power On, Auto source search, Direct Power on/off, Edge Blending, Freeze image, Horizontal and vertical keystone correction, Lens position memory, Long light source life, OSD copy function, Point correction, Power on button, Quick Corner, Sch |
| Power consumption | 902 Watt (Normal On-Mode), 1,083 Watt (Normal Peak-mode), 773 Watt (Eco Peak-Mode), 0.4 Watt (Energy saving standby) |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Harmonized System (HS) code | 85286200 |
| Pallet gross height | 149 cm |
| Pallet gross length | 120 cm |
| Pallet gross width | 80 cm |
| Pallet height (UK) | 149 cm |
| Pallet length (UK) | 120 cm |
| Products per pallet | 4 pc(s) |
| Products per pallet (UK) | 4 pc(s) |
| Products per pallet layer | 1 pc(s) |
| Products per pallet layer (UK) | 1 pc(s) |
Other features
| Specification | Value |
|---|---|
| Interface | USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), VGA in, DVI in, HDMI in, HDBaseT, Jack plug out, Wireless LAN IEEE 802.11a/b/g/n (optional), Near Field Communication (NFC), USB content playback, Remote |
| Security features | Kensington lock, Security bar, Password lock, Wireless LAN unit lock, Wireless LAN security, Password protection |
| Supported network protocols | HTTPS, IPv6, SNMP, ESC/VP.net, PJLink |
| Option type | Camera module, Ceiling mount, Wireless LAN unit |
| Box contents | Cable cover, Document Pack, Information sheet, Lens connector cap, Main unit, Power cable, Quick Start Guide, Remote control incl. batteries |
| Control panel | 1.03 inch with C2 Fine |
