EB-L895U
Model EB-L895UPart no. V11HB27140EAN 8715946737966
101 specifications
- Display1.7 cm (0.67")
- ConnectivityWired
- Noise36 dB
- TypeStandard throw projector
- Weight8.5 kg
- ColourBlack
Overview
- Display
- 1.7 cm (0.67")
- Connectivity
- Wired
- Noise
- 36 dB
- Type
- Standard throw projector
- Weight
- 8.5 kg
- Colour
- Black
- Brand
- Epson
- Category
- Data Projector
- Model
- EB-L895U
- Part numbers
- V11HB27140, V11HB27153BU
- EAN / UPC
- 8715946737966
- Also known as
- Epson EB-L895U
Specifications
101 specifications in 17 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 8000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 5000000:1 |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 16:10, 21:9 |
| Smart projector | Yes |
| Screen size compatibility | 1270 - 12700 mm (50 - 500") |
| Projection distance | 1.44 - 23.84 m |
| Projection distance (wide) | 1.4 - 14.8 m |
| Projection distance (tele) | 2.4 - 23.8 m |
| Contrast ratio (dynamic) | 5000000:1 |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 5600 ANSI lumens |
| Keystone correction, horizontal | ±30° |
| Keystone correction, vertical | ±30° |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 20 - 31.8 mm |
| Aperture range (F-F) | 1.5 - 1.7 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Zoom ratio | 1.6:1 |
| Throw ratio | 1.35 - 2.20:1 |
| Horizontal lens shift range | -20 - -20% |
| Vertical lens shift range | -50 - -50% |
Video
| Specification | Value |
|---|---|
| Colour modes (2D) | Cinema, Dynamic, Natural, DICOM SIM, Presentation |
| Supported graphics resolutions | 1920 x 1200 (WUXGA) |
| Video colour modes | BT.709, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation |
| Video processing | 10 bit |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| HDBaseT port | Yes |
| Serial interface type | RS-232C |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | Yes |
| Miracast | Yes |
| Apple AirPlay 2 support | Yes |
Features
| Specification | Value |
|---|---|
| Noise level | 36 dB |
| Noise level (economic mode) | 26 dB |
| Screen mirroring | Yes |
| Air filter | Yes |
| Country of origin | Philippines |
| Password protection | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Home cinema |
| Housing material | Plastic |
| Product colour | Black |
| Placement | Ceiling, Desktop |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 1.7 cm (0.67") |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 388 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (max) | 450 W |
| Power consumption (economy mode) | 266 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 8.5 kg |
| Width | 440 mm |
| Depth | 340 mm |
| Height | 138 mm |
| Package width | 505 mm |
| Package depth | 515 mm |
| Package height | 235 mm |
| Package weight | 12.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | Power |
Technical details
| Specification | Value |
|---|---|
| Mobile app support | Yes |
| Other features | 21:9 aspect ratio support, A/V mute, Auto Power On, Built-in speaker, Customizable user logo, Direct Power on/off, Document Camera Compatible, Edge Blending, Home Screen, JPEG Viewer, Network projection, OSD copy function, PC Free, Point correction, Quick Corner, Schedule Function, Screen Mirroring, |
| Sustainability certificates | TCO |
| Power consumption | 388 Watt (Normal On-Mode), 266 Watt (Eco On-Mode), 450 Watt (Normal Peak-mode), 330 Watt (Eco Peak-Mode), 0.4 Watt (Energy saving standby) |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Pallet gross height | 2.03 m |
| Pallet gross length | 120 cm |
| Pallet gross width | 80 cm |
| Pallet height (UK) | 2.03 m |
| Pallet length (UK) | 120 cm |
| Products per pallet | 16 pc(s) |
| Products per pallet (UK) | 16 pc(s) |
| Products per pallet layer | 2 pc(s) |
| Products per pallet layer (UK) | 2 pc(s) |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Interface | USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, HDMI out, HDBaseT, Miracast, Jack plug out, HDMI (HDCP 2.3) (2x), Near Field Communication (NFC), Apple AirPlay 2 |
| Security features | Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Password protection |
| Supported network protocols | HTTPS, SNMP, ESC/VP.net, PJLink |
| Option type | Air filter, Camera module, Ceiling mount, Document camera, External Speaker, HDBaseT Transmitter, Safety wire set, Suspension adapter, WP System - ELPWP20 |
| Box contents | Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, User guide, Warranty document |
| Control panel | 0.67 inch with C2 Fine |
