EB-L690SU
Epson

EB-L690SU

Model EB-L690SUPart no. V11HB31040EAN 8715946738000

106 specifications
  • Display1.7 cm (0.67")
  • Noise34 dB
  • TypeShort throw projector
  • Weight8.9 kg
  • ColourWhite
  • Projector brightness6200 ANSI lumens
See all specifications

Overview

Display
1.7 cm (0.67")
Noise
34 dB
Type
Short throw projector
Weight
8.9 kg
Colour
White
Projector brightness
6200 ANSI lumens
Brand
Epson
Model
EB-L690SU
Part numbers
V11HB31040, V11HB31080
EAN / UPC
8715946738000
Also known as
Epson EB-L690SU

Specifications

106 specifications in 18 groups

Projector

Projector brightness6200 ANSI lumens
Projection technology3LCD
Projector native resolutionWUXGA (1920x1200)
Contrast ratio (typical)5000000:1
Native aspect ratio16:10
Supported aspect ratios16:10, 16:6, 21:9
Screen size compatibility1524 - 10160 mm (60 - 400")
Projection distance1.02 - 11.89 m
Projection distance (wide)1 - 7 m
Projection distance (tele)1.8 - 11.9 m
Contrast ratio (dynamic)5000000:1
Number of colours1.07 billion colours
Projector brightness (economic mode)4340 ANSI lumens
Keystone correction, horizontal±30°
Keystone correction, vertical±30°

Light source

Light source typeLaser
Service life of light source20000 h
Service life of light source (economic mode)30000 h

Lens system

FocusManual
Focal length range11.6 - 19.9 mm
Aperture range (F-F)1.7 - 2.1
Zoom capabilityYes
Zoom typeManual
Zoom ratio1.7:1
Throw ratio0.79 - 1.36:1
Horizontal lens shift range-20 - -20%
Vertical lens shift range-50 - -50%

Video

Analog signal format systemNot supported
Full HDYes
3DNo
Colour modes (2D)Cinema, Dynamic, Natural, DICOM SIM, Presentation
Video colour modesBT.709, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation
Video processing10 bit

Ports & interfaces

VGA (D-Sub) ports quantity0
HDMI ports quantity2
DVI portNo
HDBaseT portYes
USB 2.0 ports quantity3
USB 2.0 Type-A ports quantity2
USB 2.0 Type-B ports quantity1
Serial interface typeRS-232C

Network

Ethernet LANYes
Ethernet LAN data rates10,100 Mbit/s
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
MiracastYes
Apple AirPlay 2 supportYes

Storage

Card reader integratedNo

Features

InteractiveNo
Noise level34 dB
Noise level (economic mode)25 dB
HDCPYes
Preset modesCinema, Dynamic, Presentation
On Screen Display (OSD)Yes
HDCP version2.3
Country of originPhilippines
Password protectionYes

Multimedia

Built-in speaker(s)Yes
RMS rated power10 W

Design

Product typeShort throw projector
Market positioningEducation
Product colourWhite
PlacementCeiling, Desktop
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayYes
DisplayLCD
Display diagonal1.7 cm (0.67")

Power

Power sourceAC
Power consumption (typical)336 W
Power consumption (standby)0.4 W
Power consumption (max)399 W
Power consumption (economy mode)233 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
AC adapter output voltage100 - 240 V

Operational conditions

Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Weight8.9 kg
Width440 mm
Depth362 mm
Height151 mm
Package width510 mm
Package depth545 mm
Package height230 mm
Package weight12.3 kg

Packaging content

Remote control includedYes
Batteries includedYes
Cables includedPower

Technical details

Mobile app supportYes
Other features21:9 aspect ratio support, A/V mute, Auto Power On, Built-in speaker, Customizable user logo, Direct Power on/off, Document Camera Compatible, Edge Blending, Home Screen, JPEG Viewer, Network projection, OSD copy function, PC Free, Point correction, Quick Corner, Schedule Function, Screen Mirroring,
Power consumption336 Watt (Normal On-Mode), 233 Watt (Eco On-Mode), 399 Watt (Normal Peak-mode), 295 Watt (Eco Peak-Mode), 0.4 Watt (Energy saving standby)
Warranty period3 year(s)

Logistics data

Quantity per pack1 pc(s)
Products per pallet14 pc(s)
Products per pallet (UK)14 pc(s)
Products per pallet layer2 pc(s)
Products per pallet layer (UK)2 pc(s)

Other features

InterfaceUSB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n, HDMI out, HDBaseT, Miracast, Jack plug out, HDMI (HDCP 2.3) (2x), Near Field Communication (NFC), Apple AirPlay 2
RS-232CYes
Security featuresKensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Password protection
Supported network protocolsHTTPS, SNMP, ESC/VP.net, PJLink
Option typeAir filter, Camera module, Ceiling mount, Document camera, External Speaker, HDBaseT Transmitter, Safety wire set, Suspension adapter, WP System - ELPWP20
Box contentsMain unit, Power cable, Quick Start Guide, Remote control incl. batteries, User guide, Warranty document
Control panel0.67 inch with C2 Fine
