EB-L690SE
Model EB-L690SEPart no. V11HB36080EAN 8715946737904
93 specifications
- Noise36 dB
- TypeShort throw projector
- Weight9.3 kg
- ColourWhite
- Projector brightness6000 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 36 dB
- Type
- Short throw projector
- Weight
- 9.3 kg
- Colour
- White
- Projector brightness
- 6000 ANSI lumens
- Light source type
- Laser
- Brand
- Epson
- Category
- Data Projector
- Model
- EB-L690SE
- Part numbers
- V11HB36080, V11HB36053BU
- EAN / UPC
- 8715946737904
- Also known as
- Epson EB-L690SE
Specifications
93 specifications in 17 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 6000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 5000000:1 |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 2540 - 12700 mm (100 - 500") |
| Projection distance | 1.09 - 7.84 m |
| Projection distance (wide) | 1.1 - 5.6 m |
| Projection distance (tele) | 1.5 - 7.8 m |
| Contrast ratio (dynamic) | 5000000:1 |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 4200 ANSI lumens |
| Keystone correction, horizontal | ±30° |
| Keystone correction, vertical | ±30° |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 7.54 - 10.55 mm |
| Aperture range (F-F) | 1.8 - 2 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Zoom ratio | 1.4:1 |
| Throw ratio | 0.50 - 0.70:1 |
| Horizontal lens shift range | -20 - -20% |
| Vertical lens shift range | -50 - -50% |
Video
| Specification | Value |
|---|---|
| Analog signal format system | Not supported |
| Full HD | Yes |
| 3D | No |
| Colour modes (2D) | Cinema, Dynamic, Natural, DICOM SIM, Presentation |
| Video colour modes | BT.709, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation |
| Video processing | 10 bit |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 2 |
| HDMI version | 2.3 |
| DVI port | No |
| HDBaseT port | Yes |
| USB 2.0 ports quantity | 3 |
| USB 2.0 Type-A ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Serial interface type | RS-232C |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Miracast | Yes |
| Apple AirPlay 2 support | Yes |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 36 dB |
| Noise level (economic mode) | 26 dB |
| HDCP | Yes |
| Preset modes | Cinema, Dynamic, Presentation |
| Country of origin | Philippines |
| Password protection | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Product type | Short throw projector |
| Market positioning | Education |
| Product colour | White |
| Placement | Ceiling, Desktop |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 362 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (max) | 415 W |
| Power consumption (economy mode) | 250 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| AC adapter output voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 9.3 kg |
| Width | 440 mm |
| Depth | 368 mm |
| Height | 151 mm |
| Package width | 510 mm |
| Package depth | 545 mm |
| Package height | 230 mm |
| Package weight | 13.3 kg |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
Technical details
| Specification | Value |
|---|---|
| Other features | 21:9 aspect ratio support, 4K enhancement, A/V mute, Auto Power On, Customizable user logo, Direct Power on/off, Document Camera Compatible, Edge Blending, Home Screen, JPEG Viewer, Network projection, OSD copy function, PC Free, Point correction, Quick Corner, Schedule Function, Split-Screen-Functi |
| Power consumption | 362 Watt (Normal On-Mode), 250 Watt (Eco On-Mode), 415 Watt (Normal Peak-mode), 303 Watt (Eco Peak-Mode), 0.4 Watt (Energy saving standby) |
| Warranty period | 3 year(s) |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
Other features
| Specification | Value |
|---|---|
| Interface | USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n (optional), HDMI out, HDBaseT, Jack plug out, HDMI (HDCP 2.3) (2x), Near Field Communication (NFC) |
| Security features | Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Password protection |
| Supported network protocols | HTTPS, SNMP, ESC/VP.net, PJLink |
| Option type | Air filter, Camera module, Ceiling mount, Document camera, External Speaker, HDBaseT Transmitter, Safety wire set, Suspension adapter, Wireless LAN unit |
| Box contents | Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, User guide, Warranty document |
| Control panel | 0.67 inch with C2 Fine |
