Epson EB-810E
Epson

EB-810E

Model EB-810EPart no. V11HA99080EAN 8715946718156

101 specifications
  • Noise35 dB
  • TypeUltra short throw projector
  • Weight12.5 kg
  • ColourWhite
  • Projector brightness5000 ANSI lumens
  • Light source typeLaser
See all specifications

Overview

Noise
35 dB
Type
Ultra short throw projector
Weight
12.5 kg
Colour
White
Projector brightness
5000 ANSI lumens
Light source type
Laser
Brand
Epson
Model
EB-810E
Part numbers
V11HA99080, 810EBU120ALR, V11HA99053
EAN / UPC
8715946718156, 9314020637681
Also known as
Epson EB-810E

Specifications

101 specifications in 18 groups

Projector

Projector brightness5000 ANSI lumens
Projection technology3LCD
Projector native resolution1080p (1920x1080)
Contrast ratio (typical)2500000:1
Native aspect ratio16:9
Smart projectorNo
Screen size compatibility2032 - 4064 mm (80 - 160")
Contrast ratio (dynamic)5000000:1
Projector brightness (economic mode)3500 ANSI lumens
Vertical scan range192 - 240 Hz
Heat dissipation1292 BTU/h

Light source

Light source typeLaser
Service life of light source20000 h
Service life of light source (economic mode)30000 h

Lens system

FocusManual
Focal length range2.3 mm
Fixed focal length2.3 mm
F-number (relative aperture)1.8
Zoom capabilityYes
Zoom ratio1.35:1
Throw ratio0.16 - 0.22:1

Video

Analog signal format systemNot supported
Full HDYes
3DNo
Colour modes (2D)Cinema, Dynamic, Natural, Blackboard, DICOM SIM, Presentation
Video colour modesBlackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation
Video processing10 bit

Ports & interfaces

VGA (D-Sub) ports quantity0
HDMI ports quantity3
Component video (YPbPr/YCbCr) in0
Composite video in0
DVI portNo
HDBaseT portYes
Service port typeUSB Type-B
USB 2.0 ports quantity2
USB 2.0 Type-A ports quantity2
Serial interface typeRS-232C

Network

Smart TVNo
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100 Mbit/s
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
MiracastYes

Storage

Card reader integratedNo

Features

InteractiveNo
Noise level35 dB
Noise level (economic mode)26 dB
High Dynamic Range (HDR) supportedYes
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Password protectionYes

Multimedia

Built-in speaker(s)No

Design

Product typeUltra short throw projector
Market positioningBusiness
Product colourWhite
PlacementCeiling, Desktop, TV cabinet, Wall
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)290 W
Power consumption (max)380 W
Power consumption (PowerSave)0.4 W
Power consumption (economy mode)286 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)-10 - 60 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Weight12.5 kg
Width695 mm
Depth341 mm
Height156 mm
Package width460 mm
Package depth790 mm
Package height325 mm
Package weight16.9 kg

Packaging content

Remote control includedYes
Batteries includedYes
Cables includedAC
Bundled softwareEpson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management, Epson Setting Assistant

Technical details

Mobile app supportYes
Other features21:9 aspect ratio support, 4K enhancement, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Daisy chain Multi-Projection, Digital zoom, Direct Power on/off, Document Camera Compatible, Edge Blending, Email notification, Fit to Scr
Power consumption290 Watt (Normal On-Mode), 192 Watt (Eco On-Mode), 380 Watt (Normal Peak-mode), 286 Watt (Eco Peak-Mode), 0.4 Watt (Energy saving standby)

Logistics data

Quantity per pack1 pc(s)
Pallet gross height2.1 m
Pallet gross length120 cm
Pallet gross width80 cm
Pallet height (UK)2.1 m
Pallet length (UK)120 cm
Products per pallet12 pc(s)
Products per pallet (UK)12 pc(s)
Products per pallet layer2 pc(s)
Products per pallet layer (UK)2 pc(s)

Other features

InterfaceUSB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, HDMI in (2x), HDMI out, HDBaseT, Miracast
Security featuresKensington lock, Control panel lock, Password lock, Padlock, Wireless LAN unit lock, Wireless LAN security, Password protection
Supported network protocolsHTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Option typeAir filter, Ceiling mount, Connection and control box, MB22 ceiling mount, Safety wire set, Visualiser camera, WP System - ELPWP10, WP System - ELPWP20, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01
Box contentsPower cable, Quick Start Guide, Remote control incl. batteries, Warranty Documents
Control panel0.62 inch with C2 Fine
