EB-760W
Epson

EB-760W

Model EB-760WPart no. V11HA81080EAN 5715063076293

108 specifications
  • Noise37 dB
  • TypeUltra short throw projector
  • Weight5.9 kg
  • ColourWhite
  • Projector brightness4100 ANSI lumens
  • Light source typeLaser
See all specifications

Overview

Noise
37 dB
Type
Ultra short throw projector
Weight
5.9 kg
Colour
White
Projector brightness
4100 ANSI lumens
Light source type
Laser
Brand
Epson
Model
EB-760W
Part number
V11HA81080
EAN / UPC
5715063076293, 8715946715285
Also known as
Epson EB-760W

Specifications

108 specifications in 19 groups

Projector

Projector brightness4100 ANSI lumens
Projection technology3LCD
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)2500000:1
Native aspect ratio16:10
Supported aspect ratios16:10
Screen size compatibility1524 - 3810 mm (60 - 150")
Contrast ratio (dynamic)5000000:1
Number of colours1.07 billion colours
Projector brightness (economic mode)2800 ANSI lumens
Vertical scan range100 - 120 Hz
Keystone correction, horizontal±3°
Keystone correction, vertical±3°
Heat dissipation895 BTU/h

Light source

Light source typeLaser
Service life of light source20000 h
Service life of light source (economic mode)30000 h

Lens system

FocusManual
Focal length range3.7 mm
Fixed focal length3.7 mm
F-number (relative aperture)1.6
Zoom capabilityYes
Zoom ratio1.35:1
Throw ratio0.27 - 0.37:1

Video

Full HDNo
3DNo
Video colour modesBlackboard, Cinema, Dynamic, Presentation, sRGB
Video processing10 bit

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity3
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portNo
USB 2.0 ports quantity3
USB 2.0 Type-A ports quantity2
USB 2.0 Type-B ports quantity1
Audio (L/R) in3
Audio (L/R) out1
Microphone inYes
Serial interface typeRS-232C
Consumer Electronics Control (CEC) supportYes
Audio Return Channel (ARC)Yes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100 Mbit/s
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
MiracastYes

Storage

Card reader integratedNo

Features

Noise level37 dB
Noise level (economic mode)27 dB
On Screen Display (OSD)Yes
Screen mirroringYes
Country of originPhilippines
Password protectionYes

Multimedia

Built-in speaker(s)Yes
RMS rated power16 W

Design

Product typeUltra short throw projector
Market positioningPresentation
Product colourWhite
PlacementCeiling, Desktop, Wall
Cable lock slotYes
Cable lock slot typeKensington

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)197 W
Power consumption (standby)0.5 W
Power consumption (max)263 W
Power consumption (PowerSave)199 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Supplier features

Recommended genderAny gender

Operational conditions

Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Weight5.9 kg
Width356 mm
Depth395 mm
Height133 mm
Package width450 mm
Package depth485 mm
Package height325 mm
Package weight8.74 kg

Packaging content

Remote control includedYes
Batteries includedYes
Cables includedAC
ManualYes
Bundled softwareEasyMP Multi PC Projection, Epson Classroom Connect, Epson Projector Content Manager, Epson Projector Management

Technical details

Mobile app supportYes
Other featuresA/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light sou
Power consumption197 Watt (Normal On-Mode), 141 Watt (Eco On-Mode), 263 Watt (Normal Peak-mode), 199 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby)
Warranty period5 year(s)

Logistics data

Quantity per pack1 pc(s)
Pallet gross height2.1 m
Pallet gross length120 cm
Pallet gross width80 cm
Pallet height (UK)2.1 m
Pallet length (UK)120 cm
Products per pallet12 pc(s)
Products per pallet (UK)24 pc(s)
Products per pallet layer2 pc(s)
Products per pallet layer (UK)4 pc(s)

Other features

InterfaceUSB 2.0-A (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), USB 2.0 Type B (Service Only), Wi-Fi Direct, Microphone input
Security featuresKensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
Supported network protocolsHTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Option typeAir filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01
Box contentsPower cable, Projector feet, Quick Start Guide, Remote control incl. batteries, Warranty document
Control panel0.59 inch with C2 Fine
