Epson EB-696Ui Ultra short throw projector 3800 ANSI lumens 3LCD WUXGA (1920x1200) Grey, White

Epson EB-696Ui Ultra short throw projector 3800 ANSI lumens 3LCD WUXGA (1920x1200) Grey, White

Model EB-696UiPart no. V11H728040EAN 8715946605111

97 specifications
  • Noise37 dB
  • TypeUltra short throw projector
  • Weight8.3 kg
  • ColourGrey, White
  • Projector brightness3800 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Noise
37 dB
Type
Ultra short throw projector
Weight
8.3 kg
Colour
Grey, White
Projector brightness
3800 ANSI lumens
Light source type
Lamp
Brand
Epson
Model
EB-696Ui
Part numbers
V11H728040, V11H728041
EAN / UPC
8715946605111, 5057454547242, 8715946605128
Also known as
Epson EB-696Ui Ultra short throw projector 3800 ANSI lumens 3LCD WUXGA (1920x1200) Grey, White

Specifications

97 specifications in 18 groups

Projector

Projector brightness3800 ANSI lumens
Projection technology3LCD
Projector native resolutionWUXGA (1920x1200)
Contrast ratio (typical)300:1
Native aspect ratio16:10
Supported aspect ratios16:10
Screen size compatibility1778 - 2540 mm (70 - 100")
Projection distance (wide)0 - 0.4 m
Projection distance (tele)0 - 0.6 m
Contrast ratio (dynamic)16000:1
Number of colours1.073 billion colours
Projector brightness (economic mode)2700 ANSI lumens
Colour light output3800 ANSI lumens
Keystone correction, horizontal±3°
Keystone correction, vertical±3°
Matrix size1.7 cm (0.67")
Vertical synchronization (max)0.24 kHz
Vertical synchronization (min)0.192 kHz
White light output3800 ANSI lumens

Light source

Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Lamp power267 W

Lens system

FocusManual
Zoom ratio1.35:1
Digital zoom1.35x
Throw ratio0.27 - 0.37:1

Video

Full HDYes
3DNo
Supported graphics resolutions1920 x 1200 (WUXGA)
Video processing10 bit

Ports & interfaces

VGA (D-Sub) ports quantity3
HDMI ports quantity3
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portNo
S-Video inputs quantity1
USB 2.0 ports quantity3
Audio (L/R) in1
Headphone outputs1
Microphone inYes
Serial interface typeRS-232C
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1

Storage

Card reader integratedNo

Features

InteractiveYes
Noise level37 dB
Noise level (economic mode)30 dB
Country of originPhilippines

Multimedia

Built-in speaker(s)Yes
RMS rated power16 W

Design

Product typeUltra short throw projector
Market positioningUlta short throw
Product colourGrey, White
PlacementWall
Cable lock slotYes
Cable lock slot typeKensington
LED indicatorsYes

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)400 W
Power consumption (standby)0.5 W
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz

Software

Mac compatibilityYes
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supportedYes

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Weight8.3 kg
Width474 mm
Depth447 mm
Height130 mm
Package width580 mm
Package depth785 mm
Package height335 mm
Package weight25 kg

Packaging content

Remote control includedNo
ManualYes

Logistics data

Quantity per pack1 pc(s)
Harmonized System (HS) code85286200
Pallet gross height15 cm
Pallet gross length120 cm
Pallet gross width80 cm
Pallet height (UK)15 cm
Pallet length (UK)120 cm
Pallet width (UK)100 cm
Products per pallet12 pc(s)
Products per pallet (UK)12 pc(s)
Products per pallet layer2 pc(s)
Products per pallet layer (UK)2 pc(s)

Other features

RS-232 ports1
RS-232CYes
