Epson Bright Link 685Wi+

Epson Bright Link 685Wi+

Model Bright Link 685Wi+Part no. V11H741021EAN 010343924734

91 specifications
  • Noise35 dB
  • TypeUltra short throw projector
  • Weight5.8 kg
  • ColourGrey, White
  • Projector brightness3500 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Noise
35 dB
Type
Ultra short throw projector
Weight
5.8 kg
Colour
Grey, White
Projector brightness
3500 ANSI lumens
Light source type
Lamp
Brand
Epson
Model
Bright Link 685Wi+
Part number
V11H741021
EAN / UPC
010343924734
Also known as
Epson PowerLite Bright Link 685Wi+ Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) Grey, White

Specifications

91 specifications in 18 groups

Projector

Projector brightness3500 ANSI lumens
Projection technology3LCD
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)14000:1
Native aspect ratio16:10
Supported aspect ratios16:10
Screen size compatibility1524 - 2540 mm (60 - 100")
Projection distance (wide)0 - 0.354 m
Projection distance (tele)0 - 0.601 m
Number of colours1.073 billion colours
Projector brightness (economic mode)1900 ANSI lumens
Colour light output3500 ANSI lumens
Keystone correction, horizontal- 3 - 3°
Keystone correction, vertical-3 - 3°
Matrix size1.5 cm (0.59")
Matrix type3-panel (p-Si TFT active)
White light output3500 ANSI lumens

Light source

Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Lamp typeUHE
Lamp power250 W
Lamps quantity1 lamp(s)

Lens system

FocusManual
Fixed focal length3.7 mm
Aperture range (F-F)1.6 - 1.6
Zoom capabilityYes
Zoom ratio1.35:1
Throw ratio0.28 - 0.37:1

Video

Full HDNo
HD-ReadyYes
3DNo
Supported graphics resolutions1280 x 800 (WXGA)
Video colour modesBlackboard, Cinema, Dynamic, Presentation, sRGB

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity3
HDMI connector typeFull-size
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portNo
S-Video inputs quantity1
USB 2.0 ports quantity2
Audio (L/R) in3
Audio (L/R) out1
Serial interface typeRS-232C
USB connector typeUSB Type-A, USB Type-B
Mobile High-Definition Link (MHL)Yes
DC-in jackYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1

Storage

Card reader integratedNo

Features

Noise level35 dB
Noise level (economic mode)29 dB
Projection modesCeiling, Front, Rear
Password protectionYes
CertificationCE

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power16 W

Design

Product typeUltra short throw projector
Market positioningShort throw
Product colourGrey, White
PlacementCeiling, Wall
Cable lock slotYes
Cable lock slot typeKensington
LED indicatorsYes

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)373 W
Power consumption (economy mode)324 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Voltage tolerance10%

Software

Windows operating systems supportedYes

Operational conditions

Operating temperature (T-T)5 - 40 °C

Weight & dimensions

Weight5.8 kg
Width367 mm
Depth400 mm
Height187 mm

Packaging content

Remote control includedYes
Remote control typeIR
Batteries includedYes
AC adapter includedYes
Cables includedAC, USB
ManualYes
Mounting brackets includedYes
Quick start guideYes

Technical details

ColourYes
Compatible productsV13H010L91 V12H777020 V13H134A49 V12H731P02 V12H005M09 V12H773010 V12H774010 V12H775010 V12H776010 V12H516020

Other features

RS-232 ports1
RS-232CYes
