Dell 7700HD Standard throw projector 5000 ANSI lumens DLP 1080p (1920x1080) Black
Model 7700HDPart no. 210-39508EAN 4058154051481
75 specifications
- Noise39 dB
- TypeStandard throw projector
- Weight7.26 kg
- ColourBlack
- Projector brightness5000 ANSI lumens
- Light source typeLamp
Overview
- Noise
- 39 dB
- Type
- Standard throw projector
- Weight
- 7.26 kg
- Colour
- Black
- Projector brightness
- 5000 ANSI lumens
- Light source type
- Lamp
- Brand
- Dell
- Category
- Data Projector
- Model
- 7700HD
- Part number
- 210-39508
- EAN / UPC
- 4058154051481, 766150038361, 884116073550, 5397063106806 +1 more
- Also known as
- DELL 7700HD Standard throw projector 5000 ANSI lumens DLP 1080p (1920x1080) Black
Specifications
75 specifications in 15 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 5000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | 1080p (1920x1080) |
| Contrast ratio (typical) | 2500:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 16:9 |
| Screen size compatibility | 515.6 - 7439.7 mm (20.3 - 292.9") |
| Projection distance | 1 - 12 m |
| Contrast ratio (dynamic) | 10000:1 |
| Uniformity | 85% |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 1500 h |
| Lamp power | 400 W |
| Lamp power (economic mode) | 2000 W |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 39.12 - 46.94 mm |
| Aperture range (F-F) | 2.6 - 2.9 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Zoom ratio | 1.2:1 |
| Throw ratio | 1.85 - 2.22:1 |
| Offset | 115% |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, NTSC 4.43, NTSC J, NTSC M, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL M, PAL Nc, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L |
| Full HD | Yes |
| 3D | No |
| Supported video modes | 1080i, 1080p, 480i, 480p, 576i, 576p, 720p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 3 |
| HDMI ports quantity | 2 |
| HDMI version | 1.3 |
| Component video (YPbPr/YCbCr) in | 1 |
| Composite video in | 1 |
| DVI port | No |
| S-Video inputs quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Headphone outputs | 2 |
| Serial interface type | RS-232 |
| USB connector type | Mini-USB B, USB Type-A, USB Type-B |
| AC (power) in | Yes |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
Features
| Specification | Value |
|---|---|
| Noise level | 39 dB |
| Noise level (economic mode) | 36 dB |
| HDCP | Yes |
| Password protection | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Product colour | Black |
| Placement | Desktop |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 525 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (PowerSave) | 20 W |
| Power consumption (economy mode) | 430 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | 0 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 7.26 kg |
| Width | 432 mm |
| Depth | 290 mm |
| Height | 135 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC, USB, VGA |
| Manual | Yes |
| Quick start guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Other features
| Specification | Value |
|---|---|
| RS-232 ports | 1 |
