Canon XEED SX 7

Canon XEED SX 7

Model XEED SX 7Part no. 2223B003BB

43 specifications
  • Display0 mm (0")
  • ConnectivityWired
  • Noise35 dB
  • Weight4.8 kg
  • Projector brightness4000 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Display
0 mm (0")
Connectivity
Wired
Noise
35 dB
Weight
4.8 kg
Projector brightness
4000 ANSI lumens
Light source type
Lamp
Brand
Canon
Model
XEED SX 7
Part numbers
2223B003BB, 2223B009
Also known as
Canon XEED SX 7 4000 ANSI lumens LCOS

Specifications

43 specifications in 13 groups

Projector

Projector brightness4000 ANSI lumens
Projection technologyLCOS
Contrast ratio (typical)1000:1
Screen size compatibility1016 - 7620 mm (40 - 300")
Uniformity88%
Horizontal scan range15 - 100 kHz
Vertical scan range50 - 100 Hz
Digital gamma correctionYes
Keystone correction, horizontal20°
Keystone correction, vertical20°

Light source

Light source typeLamp
Lamp power275 W

Lens system

FocusAuto/Manual
Focal length range21.7 - 35.8 mm
Digital zoom12x

Video

HD-ReadyYes

Ports & interfaces

VGA (D-Sub) ports quantity3
Composite video in1
DVI portYes
S-Video inputs quantity1
USB 2.0 ports quantity1
PC Audio inYes
Progressive scan outputYes

Features

Noise level35 dB
Dot clock scanning frequency170 MHz

Multimedia

RMS rated power1 W

Design

Market positioningPortable

Display

Display diagonal0 mm (0")

Power

Power consumption (typical)360 W
Power consumption (standby)7 W

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-30 - 60 °C

Weight & dimensions

Weight4.8 kg

Other features

Aspect ratio4:3
Light source275W NSH AC lamp
Audio input1
Connectivity technologyWired
Dimensions (WxDxH)266 x 336 x 114 mm
Horizontal resolution550 lines
Lamp-door protectionYes
Power requirements100V - 240V AC, 50/60Hz
Resolution1470000
I/O portsDVI-I 29-pin HDCP Mini D-Sub 15-pin (Component / SCART) Mini D-Sub 15-pin Mini DIN 4-pin RCA x 1 3.5mm stereo mini-jack x 3 USB Type B Mini DIN 8-pin
