Canon WUX10 Mark II

Canon WUX10 Mark II

Model WUX10 Mark IIPart no. 4321B007

75 specifications
  • ConnectivityWired
  • Noise36 dB
  • TypePortable projector
  • Weight5 kg
  • ColourGrey, Silver
  • Projector brightness3200 ANSI lumens
See all specifications

Overview

Connectivity
Wired
Noise
36 dB
Type
Portable projector
Weight
5 kg
Colour
Grey, Silver
Projector brightness
3200 ANSI lumens
Brand
Canon
Model
WUX10 Mark II
Part numbers
4321B007, 4231B008
Also known as
Canon XEED WUX10 Mark II Portable projector 3200 ANSI lumens LCOS WUXGA (1920x1200) Grey, Silver

Specifications

75 specifications in 16 groups

Projector

Projector brightness3200 ANSI lumens
Projection technologyLCOS
Projector native resolutionWUXGA (1920x1200)
Contrast ratio (typical)1000:1
Screen size compatibility1016 - 7620 mm (40 - 300")
Projection distance1.2 - 9.1 m
Uniformity88%
Digital gamma correctionYes
Horizontal synchronization (max)75 kHz
Horizontal synchronization (min)15 kHz
Keystone correction, vertical-20 - 20°
Matrix size1.8 cm (0.71")
Matrix type3-panel (p-Si TFT active)
Vertical synchronization (max)85 kHz
Vertical synchronization (min)50 kHz

Light source

Light source typeLamp
Service life of light source (economic mode)3000 h
Lamp typeNSHA
Lamp power275 W

Lens system

FocusAuto/Manual
Focal length range21.8 - 31.9 mm
Aperture range (F-F)1.85 - 2.65
Zoom capabilityYes
Zoom ratio1.5:1
Digital zoom12x

Video

Analog signal format systemNTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Full HDYes
3DNo
Supported graphics resolutions1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Supported video modes1035i, 1080i, 1080p, 480i, 480p, 576i, 576p, 720p

Ports & interfaces

VGA (D-Sub) ports quantity3
HDMI ports quantity1
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portYes
S-Video inputs quantity0
USB 2.0 ports quantity0
Audio (L/R) in0
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiNo

Storage

Card reader integratedNo

Features

Noise level36 dB
Noise level (economic mode)32 dB
HDCPYes
Preset modesCinema, Presentation, sRGB, Standard, Vivid photo

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers1
RMS rated power1 W

Design

Product typePortable projector
Market positioningPortable
Product colourGrey, Silver

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)400 W
Power consumption (standby)11 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-30 - 60 °C

Weight & dimensions

Weight5 kg
Width284 mm
Depth336 mm
Height114 mm

Packaging content

Remote control includedNo
Warranty cardYes

Other features

Aspect ratio16:10
Audio input3
Audio output1
Connectivity technologyWired
Maximum analog resolution1920 x 1200 pixels
Maximum digital resolution1920 x 1200 pixels
Network readyYes
RS-232 ports0
