TK860i Standard throw projector 3300 ANSI lumens DLP UHD 4K (3840x2160) 3D Grey, White
Model TK860iPart no. 9H.JR477.37EEAN 840046047559
69 specifications
- Noise30 dB
- TypeStandard throw projector
- Weight4.2 kg
- ColourGrey, White
- Projector brightness3300 ANSI lumens
- Light source typeLamp
Overview
- Noise
- 30 dB
- Type
- Standard throw projector
- Weight
- 4.2 kg
- Colour
- Grey, White
- Projector brightness
- 3300 ANSI lumens
- Light source type
- Lamp
- Brand
- BenQ
- Category
- Data Projector
- Model
- TK860i
- Part number
- 9H.JR477.37E
- EAN / UPC
- 840046047559, 4718755088421
- Also known as
- BenQ TK860i Standard throw projector 3300 ANSI lumens DLP UHD 4K (3840x2160) 3D Grey, White
Specifications
69 specifications in 16 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 3300 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | UHD 4K (3840x2160) |
| Contrast ratio (typical) | 50000:1 |
| Native aspect ratio | 16:9 |
| Smart projector | Yes |
| Screen size compatibility | 2540 - 3810 mm (100 - 150") |
| Projection distance | 2.5 - 3.8 m |
| Number of colours | 1.07 billion colours |
| Horizontal scan range | 15 - 135 kHz |
| Vertical scan range | 23 - 120 Hz |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 4000 h |
| Service life of light source (economic mode) | 15000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Auto |
| Focal length range | 12 - 15.6 mm |
| Aperture range (F-F) | 1.9 - 2.47 |
| Zoom capability | Yes |
| Zoom ratio | 1.3:1 |
| Throw ratio | 1.13 ~ 1.47 |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
| 3D | Yes |
| Video colour modes | Bright cinema, Cinema, Game, Living room, Sports |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 3 |
| Component video (YPbPr/YCbCr) in | 0 |
| Composite video in | 0 |
| DVI port | No |
| USB 2.0 ports quantity | 1 |
| Mini-USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Audio (L/R) in | 0 |
| Microphone in | Yes |
| Serial interface type | RS-232 |
| S/PDIF out port | Yes |
| AC (power) in | Yes |
| Audio Return Channel (ARC) | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | Yes |
| Ethernet LAN | No |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 30 dB |
| Noise level (economic mode) | 28 dB |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG) |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Audio decoders | Dolby Atmos |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Home cinema |
| Product colour | Grey, White |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 330 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 4.2 kg |
| Width | 380 mm |
| Depth | 263 mm |
| Height | 127 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC |
Other features
| Specification | Value |
|---|---|
| Security updates end date | 31/12/2026 |
