SX765 Standard throw projector 6000 ANSI lumens DLP XGA (1024x768) 3D White
Model SX765Part no. 9H.JKE77.24L
56 specifications
- Noise39 dB
- TypeStandard throw projector
- Weight3.7 kg
- ColourWhite
- Projector brightness6000 ANSI lumens
- Service life of light source6000 h
Overview
- Noise
- 39 dB
- Type
- Standard throw projector
- Weight
- 3.7 kg
- Colour
- White
- Projector brightness
- 6000 ANSI lumens
- Service life of light source
- 6000 h
- Brand
- BenQ
- Category
- Data Projector
- Model
- SX765
- Part number
- 9H.JKE77.24L
- Also known as
- BenQ SX765 Standard throw projector 6000 ANSI lumens DLP XGA (1024x768) 3D White
Specifications
56 specifications in 14 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 6000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | XGA (1024x768) |
| Contrast ratio (typical) | 10000:1 |
| Native aspect ratio | 4:3 |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Horizontal scan range | 15 - 102 kHz |
| Vertical scan range | 23 - 120 Hz |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
Light source
| Specification | Value |
|---|---|
| Service life of light source | 6000 h |
Lens system
| Specification | Value |
|---|---|
| Zoom capability | Yes |
| Offset | 100% |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, PAL, SECAM |
| Full HD | Yes |
| 3D | Yes |
| Supported graphics resolutions | 640 x 480 (VGA), 1920 x 1200 (WUXGA) |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 2 |
| DVI port | No |
| USB 2.0 ports quantity | 1 |
| USB 2.0 Type-B ports quantity | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| Serial interface type | RS-232 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Noise level | 39 dB |
| Noise level (economic mode) | 36 dB |
| Number of OSD languages | 28 |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 5 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Business |
| Product colour | White |
| Placement | Desktop |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 420 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 440 W |
| Power consumption (economy mode) | 330 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.7 kg |
| Width | 359.8 mm |
| Depth | 259 mm |
| Height | 120.8 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC |
| Carrying case | Yes |
