BenQ PU9220+ data projector Standard throw projector 5000 ANSI lumens DLP WUXGA (1920x1200) 3D White
Model PU9220+EAN 4718755061226
75 specifications
- Noise39 dB
- TypeStandard throw projector
- Weight8.5 kg
- ColourWhite
- Projector brightness5000 ANSI lumens
- Light source typeLamp
Overview
- Noise
- 39 dB
- Type
- Standard throw projector
- Weight
- 8.5 kg
- Colour
- White
- Projector brightness
- 5000 ANSI lumens
- Light source type
- Lamp
- Brand
- BenQ
- Category
- Data Projector
- Model
- PU9220+
- Part number
- PU9220+
- EAN / UPC
- 4718755061226
- Also known as
- BenQ PU9220+ data projector Standard throw projector 5000 ANSI lumens DLP WUXGA (1920x1200) 3D White
Specifications
75 specifications in 13 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 5000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 4000:1 |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 16:10 |
| Number of colours | 1.073 billion colours |
| Horizontal scan range | 15 - 102 kHz |
| Vertical scan range | 32 - 120 Hz |
| Keystone correction, vertical | ±30° |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 1500 h |
| Service life of light source (economic mode) | 2000 h |
| Lamp power | 370 W |
| Lamps quantity | 1 lamp(s) |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 22.8 - 28.5 mm |
| Aperture range (F-F) | 2.46 - 2.56 |
| Zoom capability | Yes |
| Zoom type | Auto |
| Zoom ratio | 1.25:1 |
| Throw ratio | 1.54 - 1.93:1 |
| Horizontal lens shift range | -15 - 55% |
| Vertical lens shift range | -5 - 5% |
| Number of optional lenses supported | 5 |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, PAL, SECAM |
| Full HD | No |
| 3D | Yes |
| Supported graphics resolutions | 640 x 480 (VGA), 1920 x 1200 (WUXGA) |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Video colour modes | Bright cinema, Cinema, Presentation, sRGB |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI connector type | Full-size |
| HDMI version | 1.4 |
| Component video (YPbPr/YCbCr) in | 1 |
| Composite video in | 1 |
| DVI port | Yes |
| DisplayPorts quantity | 1 |
| S-Video inputs quantity | 1 |
| USB 2.0 ports quantity | 2 |
| Audio (L/R) in | 2 |
| Audio (L/R) out | 1 |
| Serial interface type | RS-232 |
| PC in (D-Sub) | Yes |
| Remote (IR) output | 2 |
| BNC input ports | 1 |
| 12V trigger | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Features
| Specification | Value |
|---|---|
| Noise level | 39 dB |
| Noise level (economic mode) | 34 dB |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Arabic, Bulgarian, Simplified Chinese, Traditional Chinese, Croatian, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Swedish, Turkish |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Product colour | White |
| Placement | Desktop, Ceiling |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 445 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (network standby) | 6 W |
| Power consumption (economy mode) | 340 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 8.5 kg |
| Width | 431 mm |
| Depth | 321 mm |
| Height | 167 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | No |
| Cables included | VGA |
| Manual | Yes |
| Quick start guide | Yes |
| Warranty card | Yes |
Technical details
| Specification | Value |
|---|---|
| Contrast ratio | 4000:1 |
Other features
| Specification | Value |
|---|---|
| RS-232 ports | 1 |
