LW500ST Standard throw projector 2000 ANSI lumens DLP WXGA (1280x800) 3D White
Model LW500STPart no. 9H.JRL77.13EEAN 840046047870
73 specifications
- Noise32 dB
- TypeStandard throw projector
- Weight2.3 kg
- ColourWhite
- Projector brightness2000 ANSI lumens
- Light source typeLED
Overview
- Noise
- 32 dB
- Type
- Standard throw projector
- Weight
- 2.3 kg
- Colour
- White
- Projector brightness
- 2000 ANSI lumens
- Light source type
- LED
- Brand
- BenQ
- Category
- Data Projector
- Model
- LW500ST
- Part number
- 9H.JRL77.13E
- EAN / UPC
- 840046047870, 4718755089756, 4718755089923
- Also known as
- BenQ LW500ST Standard throw projector 2000 ANSI lumens DLP WXGA (1280x800) 3D White
Specifications
73 specifications in 17 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 2000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | WXGA (1280x800) |
| Contrast ratio (typical) | 20000:1 |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 4:3, 16:10 |
| Screen size compatibility | 2387.6 - 3581.4 mm (94 - 141") |
| Projection distance (wide) | 1.7 - 3.8 m |
| Number of colours | 1.07 billion colours |
| Horizontal scan range | 15 - 135 kHz |
| Vertical scan range | 23 - 120 Hz |
| Colour gamut | 98% |
| Keystone correction, horizontal | 30° |
| Keystone correction, vertical | 20° |
Light source
| Specification | Value |
|---|---|
| Light source type | LED |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
Lens system
| Specification | Value |
|---|---|
| Zoom capability | Yes |
| Zoom ratio | 1.2:1 |
| Throw ratio | 0.72 - 0.87 |
| Offset | 100% |
Video
| Specification | Value |
|---|---|
| Full HD | No |
| 3D | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI connector type | Full-size |
| HDMI version | 1.4a/1.4b |
| DVI port | No |
| DisplayPorts quantity | 1 |
| USB 2.0 ports quantity | 1 |
| USB 2.0 Type-A ports quantity | 1 |
| Serial interface type | RS-232 |
| PC Audio out | Yes |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | No |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 32 dB |
| Noise level (economic mode) | 28 dB |
| HDCP | Yes |
| Projection modes | Ceiling, Front |
| Preset modes | Golf, 3D, Bright, Presentation, Spreadsheet, sRGB |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Presentation |
| Product colour | White |
| Placement | Ceiling, Desktop |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| LED indicators | Light, Power, Temperature |
| Heavy metals free | Hg (mercury) |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 165 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Auto power off | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.3 kg |
| Width | 296 mm |
| Depth | 238.6 mm |
| Height | 119.6 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC |
| Manual | Yes |
Technical details
| Specification | Value |
|---|---|
| Image lag time | 33.4 ms |
Other features
| Specification | Value |
|---|---|
| Picture mode | 3D ,Bright ,Golf ,Presentation ,Spreadsheet ,sRGB ,User 1 ,User 2 ,Video |
| Security updates end date | 31/12/2025 |
