LU9750 Standard throw projector 8500 ANSI lumens DLP WUXGA (1920x1200) Black
Model LU9750Part no. 9H.JPN77.25EEAN 4718755087356
62 specifications
- Noise38 dB
- TypeStandard throw projector
- Weight26.4 kg
- ColourBlack
- Projector brightness8500 ANSI lumens
- Light source typeLaser
Overview
- Noise
- 38 dB
- Type
- Standard throw projector
- Weight
- 26.4 kg
- Colour
- Black
- Projector brightness
- 8500 ANSI lumens
- Light source type
- Laser
- Brand
- BenQ
- Category
- Data Projector
- Model
- LU9750
- Part numbers
- 9H.JPN77.25E, 9H.JPG77.15L
- EAN / UPC
- 4718755087356, 840046046392
- Also known as
- BenQ LU9750 Standard throw projector 8500 ANSI lumens DLP WUXGA (1920x1200) Black
Specifications
62 specifications in 14 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 8500 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Screen size compatibility | 1270 - 12700 mm (50 - 500") |
| Number of colours | 1.07 billion colours |
| Horizontal scan range | 15 - 135 kHz |
| Vertical scan range | 23 - 120 Hz |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 38000 h |
Lens system
| Specification | Value |
|---|---|
| Horizontal lens shift range | -5 - 5% |
| Vertical lens shift range | -15 - 55% |
| Number of optional lenses supported | 9 |
| Offset | 9% |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
| Supported video modes | 720p, 1080i, 1080p, 2160p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| Component video (YPbPr/YCbCr) in | 0 |
| Composite video in | 0 |
| DVI port | Yes |
| USB 2.0 ports quantity | 0 |
| USB 2.0 Type-B ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Audio (L/R) in | 1 |
| Serial interface type | RS-232 |
| PC in (D-Sub) | Yes |
| 3D sync port | Yes |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Noise level | 38 dB |
| Noise level (economic mode) | 35 dB |
| On Screen Display (OSD) | Yes |
| Number of OSD languages | 12 |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Business |
| Product colour | Black |
| Cable lock slot | Yes |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 792 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 885 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 26.4 kg |
| Width | 500 mm |
| Depth | 587.3 mm |
| Height | 211 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Cables included | AC |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
