BenQ 720P; 2500 ANSI LUMENS; 5.94LBS; HDMI X2; C; S-V; COM; A; 10W SPKX1; AO; CONTROL
Model 720P; 2500 ANSI LUMENS; 5.94LBS; HDMI X2; C; S-V; COM; A; 10W SPKX1; AO; CONTROLPart no. W770STEAN 840046027933
81 specifications
- Noise34 dB
- TypeShort throw projector
- Weight2.7 kg
- ColourBlack, Grey
- Projector brightness2500 ANSI lumens
- Light source typeLamp
Overview
- Noise
- 34 dB
- Type
- Short throw projector
- Weight
- 2.7 kg
- Colour
- Black, Grey
- Projector brightness
- 2500 ANSI lumens
- Light source type
- Lamp
- Brand
- BenQ
- Category
- Data Projector
- Model
- 720P; 2500 ANSI LUMENS; 5.94LBS; HDMI X2; C; S-V; COM; A; 10W SPKX1; AO; CONTROL
- Part number
- W770ST
- EAN / UPC
- 840046027933, 8400460279336
- Also known as
- BenQ 720P; 2500 ANSI LUMENS; 5.94LBS; HDMI X2; C; S-V; COM; A; 10W SPKX1; AO; CONTROL Short throw projector DLP 720p (1280x720) 3D Black, Grey
Specifications
81 specifications in 15 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 2500 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | 720p (1280x720) |
| Contrast ratio (typical) | 13000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 16:9 |
| Screen size compatibility | 914.4 - 7620 mm (36 - 300") |
| Number of colours | 1.073 billion colours |
| Horizontal scan range | 15 - 102 kHz |
| Vertical scan range | 23 - 120 Hz |
| Keystone correction, vertical | -40 - 40° |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 4000 h |
| Service life of light source (economic mode) | 6500 h |
| Lamp power | 210 W |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 10.2 - 12.24 mm |
| Aperture range (F-F) | 2.6 - 2.78 |
| Zoom ratio | 1.2:1 |
| Offset | 115% |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, PAL, SECAM |
| Full HD | No |
| HD-Ready | Yes |
| 3D | Yes |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1600 x 1200 (UXGA) |
| Supported video modes | 1080i, 1080p, 480i, 480p, 576i, 576p, 720p |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI version | 1.4a |
| Component video (YPbPr/YCbCr) in | 1 |
| Composite video in | 1 |
| DVI port | No |
| DisplayPorts quantity | 0 |
| S-Video inputs quantity | 1 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| Audio (L/R) in | 1 |
| Serial interface type | RS-232 |
| USB connector type | Mini-USB B |
| Composite video out | 0 |
| CardBus PCMCIA slot type | No |
| Digital audio optical out | 0 |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
| Ethernet LAN (RJ-45) ports | 0 |
| Wi-Fi | No |
| Bluetooth | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
| Compatible memory cards | Not supported |
Features
| Specification | Value |
|---|---|
| Noise level | 34 dB |
| Noise level (economic mode) | 30 dB |
| Preset modes | Cinema, Dynamic, Standard |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Arabic, Bulgarian, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Portuguese, Romanian, Russian, Swedish, Thai, Turkish |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 10 W |
| TV tuner integrated | No |
Design
| Specification | Value |
|---|---|
| Product type | Short throw projector |
| Product colour | Black, Grey |
| Placement | Desktop, Ceiling |
| Cable lock slot | No |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 275 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.7 kg |
| Width | 324.7 mm |
| Depth | 253.4 mm |
| Height | 113.8 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC, VGA |
| Carrying case | Yes |
| Manual | Yes |
| Warranty card | Yes |
Other features
| Specification | Value |
|---|---|
| Audio input | 1 |
| Audio output | 1 |
| Maximum digital resolution | 1600 x 1200 pixels |
| RS-232 ports | 1 |
