X1123H + CarryCase
Model X1123H + CarryCasePart no. MR.JPQ11.001+MC.JPV11.005
47 specifications
- Noise30 dB
- TypeCeiling-mounted projector
- Weight2.4 kg
- ColourBlack
- Projector brightness3600 ANSI lumens
- Light source typeLamp
Overview
- Noise
- 30 dB
- Type
- Ceiling-mounted projector
- Weight
- 2.4 kg
- Colour
- Black
- Projector brightness
- 3600 ANSI lumens
- Light source type
- Lamp
- Brand
- Acer
- Category
- Data Projector
- Model
- X1123H + CarryCase
- Part number
- MR.JPQ11.001+MC.JPV11.005
- Also known as
- Acer Essential X1123H + CarryCase Ceiling-mounted projector 3600 ANSI lumens DLP SVGA (800x600) 3D Black
Specifications
47 specifications in 14 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 3600 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | SVGA (800x600) |
| Contrast ratio (typical) | 20000:1 |
| Native aspect ratio | 4:3 |
| Supported aspect ratios | 4:3, 16:9 |
| Screen size compatibility | 685.8 - 7620 mm (27 - 300") |
| Projection distance | 1 - 10 m |
| Projector brightness (economic mode) | 2880 ANSI lumens |
| Keystone correction, horizontal | -40 - 40° |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 10000 h |
| Lamps quantity | 1 lamp(s) |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 22 - 24.1 mm |
| Aperture range (F-F) | 2.56 - 2.68 |
| Zoom type | Manual |
| Throw ratio | 1.96 - 2.15:1 |
Video
| Specification | Value |
|---|---|
| Full HD | No |
| 3D | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 1 |
| Composite video in | 1 |
| DVI port | No |
| USB 2.0 ports quantity | 1 |
| Mini-USB 2.0 ports quantity | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Noise level | 30 dB |
| Noise level (economic mode) | 26 dB |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 3 W |
Design
| Specification | Value |
|---|---|
| Product type | Ceiling-mounted projector |
| Market positioning | Business |
| Product colour | Black |
| Placement | Ceiling |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.4 kg |
| Width | 299.5 mm |
| Depth | 220 mm |
| Height | 105.1 mm |
Packaging content
| Specification | Value |
|---|---|
| Carrying case | Yes |
