X1123 Standard throw projector 4000 ANSI lumens DLP SVGA (800x600) Black
Model X1123Part no. MR.JXL11.001EAN 4711474119568
52 specifications
- TypeStandard throw projector
- Weight2.25 kg
- ColourBlack
- Projector brightness4000 ANSI lumens
- Light source typeLamp
- Digital zoom2x
Overview
- Type
- Standard throw projector
- Weight
- 2.25 kg
- Colour
- Black
- Projector brightness
- 4000 ANSI lumens
- Light source type
- Lamp
- Digital zoom
- 2x
- Brand
- Acer
- Category
- Data Projector
- Model
- X1123
- Part number
- MR.JXL11.001
- EAN / UPC
- 4711474119568
- Also known as
- Acer X1123 Standard throw projector 4000 ANSI lumens DLP SVGA (800x600) Black
Specifications
52 specifications in 15 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 4000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | SVGA (800x600) |
| Contrast ratio (typical) | 20000:1 |
| Native aspect ratio | 4:3 |
| Supported aspect ratios | 4:3, 16:9 |
| Number of colours | 1.07 billion colours |
| Horizontal synchronization (max) | 100 kHz |
| Horizontal synchronization (min) | 15 kHz |
| Keystone correction, vertical | -40 - 40° |
| Vertical synchronization (max) | 0.12 kHz |
| Vertical synchronization (min) | 0.024 kHz |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Lamp power | 220 W |
| Lamps quantity | 1 lamp(s) |
Lens system
| Specification | Value |
|---|---|
| Digital zoom | 2x |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, PAL, SECAM |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| Component video (YPbPr/YCbCr) in | 0 |
| Composite video in | 1 |
| DVI port | No |
| USB 2.0 ports quantity | 0 |
| USB 2.0 Type-A ports quantity | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| Serial interface type | RS-232 |
| AC (power) in | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Miracast | Yes |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Projection modes | Ceiling, Front, Rear |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 3 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Presentation |
| Product colour | Black |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 265 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 120 - 230 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.25 kg |
| Width | 300 mm |
| Depth | 220 mm |
| Height | 92 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| AC adapter included | Yes |
| Cables included | VGA |
| Manual | Yes |
