Acer Professional and Education U5520B Short throw projector 3000 ANSI lumens DLP 1080p (1920x1080) 3D White

Acer Professional and Education U5520B Short throw projector 3000 ANSI lumens DLP 1080p (1920x1080) 3D White

Model U5520BPart no. MR.JL311.001+SV.WPRAF.A01EAN 4713147621682

67 specifications
  • Noise29 dB
  • TypeShort throw projector
  • Weight5.5 kg
  • ColourWhite
  • Projector brightness3000 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Noise
29 dB
Type
Short throw projector
Weight
5.5 kg
Colour
White
Projector brightness
3000 ANSI lumens
Light source type
Lamp
Brand
Acer
Model
U5520B
Part numbers
MR.JL311.001+SV.WPRAF.A01, MR.JL311.001+SV.WPRAF.A02, MR.JL311.002, MR.JL311.003, MR.JL311.001
EAN / UPC
4713147621682, 4713147621699, 4053162942295, 4713147621675
Also known as
Acer Professional and Education U5520B Short throw projector 3000 ANSI lumens DLP 1080p (1920x1080) 3D White

Specifications

67 specifications in 16 groups

Projector

Projector brightness3000 ANSI lumens
Projection technologyDLP
Projector native resolution1080p (1920x1080)
Contrast ratio (typical)10000:1
Native aspect ratio16:9
Supported aspect ratios4:3, 16:9
Projection distance0.21 - 0.61 m
Number of colours1.073 billion colours
Horizontal synchronization (max)100 kHz
Horizontal synchronization (min)15 kHz
Keystone correction, horizontal-15 - 15°
Keystone correction, vertical-15 - 15°
Vertical synchronization (max)0.12 kHz
Vertical synchronization (min)0.024 kHz

Light source

Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)4000 h
Lamp typeOSRAM
Lamp power280 W
Lamps quantity1 lamp(s)

Lens system

FocusManual
Digital zoom2x
Optical zoom1x
Throw ratio0.36:1

Video

Analog signal format systemNTSC, PAL, SECAM
Full HDYes
3DYes

Ports & interfaces

VGA (D-Sub) ports quantity2
HDMI ports quantity2
Component video (YPbPr/YCbCr) in0
Composite video in1
DVI portNo
S-Video inputs quantity1
USB 2.0 ports quantity1
Audio (L/R) in1
Audio (L/R) out1
USB connector typeMini-USB B
AC (power) inYes

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Wi-FiNo

Storage

Card reader integratedNo

Features

Noise level29 dB
Noise level (economic mode)35 dB

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers2
RMS rated power20 W
Video formats supportedH.264, MPEG1, MPEG2, MPEG4, VC-1, XVID
Audio formats supportedAAC, MP1, MP2, MP3, PCM, WAV, WMA

Design

Product typeShort throw projector
Market positioningShort throw
Product colourWhite
PlacementDesktop

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)351 W
Power consumption (PowerSave)289 W

Operational conditions

Operating temperature (T-T)0 - 40 °C

Weight & dimensions

Weight5.5 kg

Packaging content

Remote control includedYes
Batteries includedYes
Cables includedAC, VGA
ManualYes
Quick start guideYes

Other features

Digital Living Network Alliance (DLNA) certifiedYes
Maximum digital resolution1920 x 1200 pixels
RS-232 ports0
