Vero PL3515 5500 ANSI lumens DLP 1080p (1920x1080) White
Model PL3515Part no. MR.JXQ11.001EAN 4711474144270
43 specifications
- Weight3 kg
- ColourWhite
- Projector brightness5500 ANSI lumens
- Light source typeLaser/LED hybrid
- FocusManual
- Full HDYes
Overview
- Weight
- 3 kg
- Colour
- White
- Projector brightness
- 5500 ANSI lumens
- Light source type
- Laser/LED hybrid
- Focus
- Manual
- Full HD
- Yes
- Brand
- Acer
- Category
- Data Projector
- Model
- PL3515
- Part number
- MR.JXQ11.001
- EAN / UPC
- 4711474144270
- Also known as
- Acer Vero PL3515 5500 ANSI lumens DLP 1080p (1920x1080) White
Specifications
43 specifications in 12 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 5500 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | 1080p (1920x1080) |
| Contrast ratio (typical) | 50000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 4:3, 16:9 |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Projection distance | 1.15 - 1.5 m |
| Projector brightness (economic mode) | 4400 ANSI lumens |
| Horizontal scan range | 15 - 100 kHz |
| Vertical scan range | 24 - 120 Hz |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser/LED hybrid |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 16.88 - 21.88 mm |
| Zoom capability | Yes |
| Zoom type | Manual |
| Vertical lens shift range | 55 - 65% |
| Offset | 110% |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0b |
| Audio (L/R) out | 1 |
| Serial interface type | RS-232 |
Features
| Specification | Value |
|---|---|
| HDCP | Yes |
| Projection modes | Front, Rear |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Market positioning | Business |
| Product colour | White |
| Placement | Ceiling |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 210 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (economy mode) | 155 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3 kg |
| Width | 304 mm |
| Depth | 226 mm |
| Height | 119 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Power |
| Carrying case | Yes |
