P1560BTi Standard throw projector 4000 ANSI lumens DLP 1080p (1920x1080) White
Model P1560BTiPart no. MR.JSY11.001EAN 4710180827088
40 specifications
- TypeStandard throw projector
- Weight2.6 kg
- ColourWhite
- Projector brightness4000 ANSI lumens
- Light source typeLamp
- Focal length range20.4 - 24.48 mm
Overview
- Type
- Standard throw projector
- Weight
- 2.6 kg
- Colour
- White
- Projector brightness
- 4000 ANSI lumens
- Light source type
- Lamp
- Focal length range
- 20.4 - 24.48 mm
- Brand
- Acer
- Category
- Data Projector
- Model
- P1560BTi
- Part numbers
- MR.JSY11.001, MR.JSY11.002, MR.JSY11.003
- EAN / UPC
- 4710180827088, 4710180827064, 4710180827071
- Also known as
- Acer P1560BTi Standard throw projector 4000 ANSI lumens DLP 1080p (1920x1080) White
Specifications
40 specifications in 11 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 4000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | 1080p (1920x1080) |
| Contrast ratio (typical) | 20000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 4:3 |
| Projection distance | 1 - 9.3 m |
| Number of colours | 1.073 billion colours |
| Horizontal synchronization (max) | 100 kHz |
| Horizontal synchronization (min) | 15 kHz |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
| Vertical synchronization (max) | 120 kHz |
| Vertical synchronization (min) | 24 kHz |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Lamp type | UHP |
| Lamp power | 210 W |
| Lamps quantity | 1 lamp(s) |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 20.4 - 24.48 mm |
| Aperture range (F-F) | 2.47 - 2.66 |
Video
| Specification | Value |
|---|---|
| Full HD | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 2 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Product colour | White |
| Placement | Ceiling |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 270 W |
| AC input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.6 kg |
