HL6810ATV Ultra HD (3840x2160) 16:9 4000lm DLP Projector
Model MR.JWW11.002EAN 4711121906596
62 specifications
- Noise29 dB
- Weight3 kg
- ColourWhite
- Projector brightness4000 ANSI lumens
- Light source typeLaser
- FocusManual
Overview
- Noise
- 29 dB
- Weight
- 3 kg
- Colour
- White
- Projector brightness
- 4000 ANSI lumens
- Light source type
- Laser
- Focus
- Manual
- Brand
- Acer
- Category
- Data Projector
- Model
- MR.JWW11.002
- Part number
- MR.JWW11.002
- EAN / UPC
- 4711121906596
- Also known as
- Acer HL6810ATV Ultra HD (3840x2160) 16:9 4000lm DLP Projector
Specifications
62 specifications in 14 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 4000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | UHD 4K (3840x2160) |
| Contrast ratio (typical) | 50000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 4:3, 16:9 |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Projection distance | 1 - 7.6 m |
| Number of colours | 1.07 billion colours |
| Uniformity | 85% |
| Horizontal scan range | 15 - 135 kHz |
| Vertical scan range | 24 - 240 Hz |
| Horizontal synchronization (max) | 135 kHz |
| Horizontal synchronization (min) | 15 kHz |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
| Vertical synchronization (max) | 0.24 kHz |
| Vertical synchronization (min) | 0.024 kHz |
Light source
| Specification | Value |
|---|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 16.88 - 21.88 mm |
| Aperture range (F-F) | 2.48 - 2.78 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Zoom ratio | 1.3:1 |
| Throw ratio | 1.15 - 1.5 |
| Vertical lens shift range | 55 - 65% |
| Offset | 110% |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 3 |
| HDMI connector type | Full-size |
| HDMI version | 2.0 |
| USB 2.0 ports quantity | 1 |
| USB 2.0 Type-A ports quantity | 1 |
| Audio (L/R) out | 1 |
| Serial interface type | RS-232 |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Features
| Specification | Value |
|---|---|
| Noise level | 29 dB |
| Noise level (economic mode) | 29 dB |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Display
| Specification | Value |
|---|---|
| Display number of colours | 1.07 billion colours |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 250 W |
| Power consumption (standby) | 0.5 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3 kg |
| Width | 304 mm |
| Depth | 226 mm |
| Height | 119 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
