H6815ATV Standard throw projector 4000 ANSI lumens DLP UHD 4K (3840x2160) White
Model H6815ATVPart no. MR.JWK11.005EAN 4711121471780
71 specifications
- Noise26 dB
- TypeStandard throw projector
- Weight3.1 kg
- ColourWhite
- Projector brightness4000 ANSI lumens
- Light source typeLamp
Overview
- Noise
- 26 dB
- Type
- Standard throw projector
- Weight
- 3.1 kg
- Colour
- White
- Projector brightness
- 4000 ANSI lumens
- Light source type
- Lamp
- Brand
- Acer
- Category
- Data Projector
- Model
- H6815ATV
- Part numbers
- MR.JWK11.005, MR.JWK11.007
- EAN / UPC
- 4711121471780, 4711121471803
- Also known as
- Acer H6815ATV Standard throw projector 4000 ANSI lumens DLP UHD 4K (3840x2160) White
Specifications
71 specifications in 14 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 4000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | UHD 4K (3840x2160) |
| Contrast ratio (typical) | 10000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 4:3, 16:9 |
| Smart projector | No |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Projection distance | 1 - 10 m |
| Number of colours | 1.07 billion colours |
| Uniformity | 75% |
| Horizontal synchronization (max) | 135 kHz |
| Horizontal synchronization (min) | 15 kHz |
| Keystone correction, horizontal | -30 - 30° |
| Keystone correction, vertical | -30 - 30° |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 12000 h |
| Lamp power | 250 W |
| Lamps quantity | 1 lamp(s) |
Lens system
| Specification | Value |
|---|---|
| Focus | Manual |
| Focal length range | 15.84 - 17.44 mm |
| Zoom ratio | 1.1:1 |
| Digital zoom | 2x |
| Optical zoom | 1.1x |
| Offset | 132% |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, PAL, SECAM |
| Digital signal format system | EDTV, HDTV, SDTV |
| Full HD | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI connector type | Full-size |
| HDMI version | 2.0 |
| Component video (YPbPr/YCbCr) in | 1 |
| DVI port | No |
| USB 2.0 ports quantity | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| Serial interface type | RS-232 |
| S/PDIF out port | Yes |
| USB connector type | USB Type-A |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | No |
| Wi-Fi | No |
| Bluetooth | No |
Features
| Specification | Value |
|---|---|
| Noise level (economic mode) | 26 dB |
| Projection modes | Ceiling, Front, Rear |
| Compatible operating systems | Mac PC Google Chrome PC Windows PC |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 10 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Presentation |
| Product colour | White |
| Placement | Ceiling |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 310 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 120 - 230 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.1 kg |
| Width | 313 mm |
| Depth | 240 mm |
| Height | 113.7 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| AC adapter included | Yes |
| Carrying case | Yes |
