Home H6523BD Standard throw projector 3500 ANSI lumens DLP 1080p (1920x1080) 3D White
Model H6523BDPart no. MR.JT111.009EAN 4710180926590
64 specifications
- TypeStandard throw projector
- Weight2.9 kg
- ColourWhite
- Projector brightness3500 ANSI lumens
- Light source typeLamp
- Focal length range15.59 - 17.14 mm
Overview
- Type
- Standard throw projector
- Weight
- 2.9 kg
- Colour
- White
- Projector brightness
- 3500 ANSI lumens
- Light source type
- Lamp
- Focal length range
- 15.59 - 17.14 mm
- Brand
- Acer
- Category
- Data Projector
- Model
- H6523BD
- Part numbers
- MR.JT111.009, MR.JT111.003, MR.JT111.002, MR.JT111.004
- EAN / UPC
- 4710180926590, 4710180926613, 4710886413455
- Also known as
- Acer Home H6523BD Standard throw projector 3500 ANSI lumens DLP 1080p (1920x1080) 3D White
Specifications
64 specifications in 16 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 3500 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | 1080p (1920x1080) |
| Contrast ratio (typical) | 10000:1 |
| Native aspect ratio | 16:9 |
| Supported aspect ratios | 4:3, 16:9 |
| Projection distance | 1 - 9.76 m |
| Number of colours | 1.073 billion colours |
| Horizontal scan range | 15 - 100 kHz |
| Vertical scan range | 24 - 120 Hz |
| Keystone correction, vertical | -40 - 40° |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 10000 h |
| Lamp power | 245 W |
| Lamps quantity | 1 lamp(s) |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 15.59 - 17.14 mm |
| Aperture range (F-F) | 2.1 - 2.31 |
| Zoom capability | Yes |
| Throw ratio | 1.47 - 1.62 |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, PAL, SECAM |
| Full HD | Yes |
| 3D | Yes |
| Video colour modes | Sports |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| HDMI version | 1.4a |
| Component video (YPbPr/YCbCr) in | 0 |
| Composite video in | 1 |
| DVI port | No |
| S-Video inputs quantity | 0 |
| USB 2.0 ports quantity | 0 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| Mobile High-Definition Link (MHL) | No |
Network
| Specification | Value |
|---|---|
| Smart TV | No |
| Ethernet LAN | No |
| Wi-Fi | No |
Storage
| Specification | Value |
|---|---|
| Card reader integrated | No |
Features
| Specification | Value |
|---|---|
| Interactive | No |
| Projection modes | Ceiling, Front, Rear |
| Eye protection | Yes |
| Compatible operating systems | Windows, MacOS |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 3 W |
Design
| Specification | Value |
|---|---|
| Product type | Standard throw projector |
| Market positioning | Presentation |
| Product colour | White |
| Placement | Ceiling |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 290 W |
| AC input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.9 kg |
| Width | 313 mm |
| Depth | 240 mm |
| Height | 114 mm |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | No |
| Cables included | AC |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Harmonized System (HS) code | 85286200 |
