BS-312P + Carrycase
Model BS-312P + CarrycasePart no. MR.JR911.00M+MC.JPV11.005
49 specifications
- TypeCeiling-mounted projector
- Weight2.8 kg
- ColourBlack
- Projector brightness4000 ANSI lumens
- Light source typeLamp
- Focal length range21.85 - 24 mm
Overview
- Type
- Ceiling-mounted projector
- Weight
- 2.8 kg
- Colour
- Black
- Projector brightness
- 4000 ANSI lumens
- Light source type
- Lamp
- Focal length range
- 21.85 - 24 mm
- Brand
- Acer
- Category
- Data Projector
- Model
- BS-312P + Carrycase
- Part number
- MR.JR911.00M+MC.JPV11.005
- Also known as
- Acer Essential BS-312P + Carrycase Ceiling-mounted projector 4000 ANSI lumens DLP WXGA (1280x800) Black
Specifications
49 specifications in 12 groups
Projector
| Specification | Value |
|---|---|
| Projector brightness | 4000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | WXGA (1280x800) |
| Contrast ratio (typical) | 20000:1 |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 4:3, 16:10, 16:9 |
| Screen size compatibility | 685.8 - 7620 mm (27 - 300") |
| Projection distance | 1 - 10 m |
| Number of colours | 1.073 billion colours |
| Horizontal synchronization (max) | 100 kHz |
| Horizontal synchronization (min) | 15 kHz |
| Keystone correction, vertical | -40 - 40° |
| Vertical synchronization (max) | 0.12 kHz |
| Vertical synchronization (min) | 0.024 kHz |
Light source
| Specification | Value |
|---|---|
| Light source type | Lamp |
| Service life of light source | 6000 h |
| Service life of light source (economic mode) | 7000 h |
| Lamp type | OSRAM |
| Lamp power | 220 W |
| Lamps quantity | 1 lamp(s) |
Lens system
| Specification | Value |
|---|---|
| Focal length range | 21.85 - 24 mm |
| Aperture range (F-F) | 21.85 - 24 |
| Zoom capability | Yes |
| Throw ratio | 1.54 to 1.72 (1524 mm @ 2000 mm) |
Video
| Specification | Value |
|---|---|
| Analog signal format system | NTSC, PAL, SECAM |
| Full HD | No |
| 3D | No |
| Supported graphics resolutions | 1280 x 800 (WXGA), 1920 x 1200 (WUXGA) |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 1 |
| Composite video in | 1 |
| USB 2.0 ports quantity | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
Features
| Specification | Value |
|---|---|
| Projection modes | Ceiling, Front, Rear |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| RMS rated power | 3 W |
Design
| Specification | Value |
|---|---|
| Product type | Ceiling-mounted projector |
| Product colour | Black |
| Placement | Ceiling |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power consumption (typical) | 275 W |
| Power consumption (economy mode) | 205 W |
| AC input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 2.8 kg |
Packaging content
| Specification | Value |
|---|---|
| Carrying case | Yes |
