3M DX70I 4200 ANSI lumens DLP XGA (1024x768) White

3M DX70I 4200 ANSI lumens DLP XGA (1024x768) White

Model DX70IPart no. 78-9236-7706-2EAN 051125633161

66 specifications
  • ConnectivityWired
  • Noise32 dB
  • Weight3.6 kg
  • ColourWhite
  • Projector brightness4200 ANSI lumens
  • Light source typeLamp
See all specifications

Overview

Connectivity
Wired
Noise
32 dB
Weight
3.6 kg
Colour
White
Projector brightness
4200 ANSI lumens
Light source type
Lamp
Brand
3M
Model
DX70I
Part number
78-9236-7706-2
EAN / UPC
051125633161
Also known as
3M DX70I 4200 ANSI lumens DLP XGA (1024x768) White

Specifications

66 specifications in 16 groups

Projector

Projector brightness4200 ANSI lumens
Projection technologyDLP
Projector native resolutionXGA (1024x768)
Contrast ratio (typical)2300:1
Screen size compatibility762 - 8890 mm (30 - 350")
Number of colours16.78 million colours
Horizontal scan range15 - 91 kHz
Vertical scan range50 - 85 Hz

Light source

Light source typeLamp
Service life of light source2000 h
Service life of light source (economic mode)3000 h
Lamp power280 W

Lens system

FocusManual
Zoom capabilityYes
Zoom typeManual
Zoom ratio1.2:1

Video

Analog signal format systemNTSC, NTSC 4.43, PAL, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
Full HDNo
HD-ReadyNo
3DNo
Supported graphics resolutions832 x 624, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Supported video modes480i, 480p

Ports & interfaces

VGA (D-Sub) ports quantity3
Component video (YPbPr/YCbCr) in1
DVI portYes
S-Video inputs quantity1
USB 2.0 ports quantity1
Audio (L/R) in1
Audio (L/R) out1
Serial interface typeRS-232
PC Audio inYes
USB connector typeUSB Type-B

Network

Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100 Mbit/s
Wi-FiNo

Storage

Card reader integratedNo

Features

Noise level32 dB
Noise level (economic mode)30 dB
CertificationUL, cUL, FCC Part 15 -Class B, CE, EN60950-1, WEEE

Multimedia

Built-in speaker(s)Yes
Number of built-in speakers2
RMS rated power2 W

Design

Product colourWhite
LED indicatorsYes

Display

Built-in displayNo

Power

Power sourceAC
Power consumption (typical)385 W
Power consumption (PowerSave)320 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Weight3.6 kg
Width335 mm
Depth250 mm
Height100 mm

Packaging content

Remote control includedYes
Quick start guideYes

Other features

Aspect ratio4:3, 16:9
Connectivity technologyWired
Maximum digital resolution1600 x 1200 pixels
Network readyYes
Power LEDYes
RS-232 ports1
