3M DX70 3800 ANSI lumens DLP XGA (1024x768)

3M DX70 3800 ANSI lumens DLP XGA (1024x768)

Model DX70Part no. 59268

33 specifications
  • Noise38 dB
  • Weight3.6 kg
  • Projector brightness3800 ANSI lumens
  • Light source typeLamp
  • FocusManual
  • Analog signal format systemNTSC, NTSC 4.43, PAL, SECAM
See all specifications

Overview

Noise
38 dB
Weight
3.6 kg
Projector brightness
3800 ANSI lumens
Light source type
Lamp
Focus
Manual
Analog signal format system
NTSC, NTSC 4.43, PAL, SECAM
Brand
3M
Model
DX70
Part numbers
59268, FF00DX70
Also known as
3M DX70 3800 ANSI lumens DLP XGA (1024x768)

Specifications

33 specifications in 13 groups

Projector

Projector brightness3800 ANSI lumens
Projection technologyDLP
Projector native resolutionXGA (1024x768)
Contrast ratio (typical)2500:1
Number of colours16.78 million colours
Horizontal scan range31.5 - 91 kHz
Vertical scan range56 - 85 Hz

Light source

Light source typeLamp
Service life of light source2000 h
Service life of light source (economic mode)3000 h
Lamp power300 W

Lens system

FocusManual
Focal length range28 - 33.6 mm

Video

Analog signal format systemNTSC, NTSC 4.43, PAL, SECAM

Ports & interfaces

VGA (D-Sub) ports quantity3
Component video (YPbPr/YCbCr) in1
Composite video in1
DVI portYes
S-Video inputs quantity1
USB 2.0 ports quantity1
Serial interface typeRS-232

Network

Ethernet LAN (RJ-45) ports1

Features

Noise level38 dB

Multimedia

Number of built-in speakers2
RMS rated power4 W

Design

Market positioningPresentation

Power

Power consumption (typical)385 W

Operational conditions

Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-20 - 60 °C

Weight & dimensions

Weight3.6 kg

Other features

Aspect ratio4:3, 16:9
Dimensions (WxDxH)335 x 250 x 100 mm
RS-232 ports1
